US$65,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Processing Type
Plastic Thermoforming Machine
Plastic Type
PP, Pet, PVC, PS, PLA
Maximum Forming Area
680X450mm
Maximum Forming Depth of Upper Mold
30mm
Maximum Forming Depth of Lower Mold
110mm
Production Speed(Cycles/Min)
10-35 Mould/Min
Video Outgoing-Inspection
Provided
Machinery Test Report
Provided
Warranty of Core Components
1 Year
Sheet Thickness(mm)
0.2-2 mm
Gas Consumption
0.5-0.8bar
Transport Package
Stretchin Film Covered Wooden Pallets for Easy Loa
Specification
Overall Dimensions 8x2.4x2.2m
Production Capacity
20 Set/Sets Per Month Plastic Yoghurt Cup Making M
Product Description
ESSENTIAL DETAILS
model | ZHD-680/450 | ZHD-750/600 | ZHD-800/650 |
Applicable sheet thickness | 0.2-2mm | 0.2-2mm | 0.2-2mm |
Applicable materials | PP PET PVC PS PLA | PP PET PVC PS PLA | PP PET PVC PS PLA |
Maximum forming area | 680x450mm | 750x600mm | 800x650mm |
Sheet width | 400-690mm | 400-800mm | 400-900mm |
Maximum forming depth of upper mold | 30mm | 120mm | 120mm |
Maximum forming depth of lower mold | 110mm | 150mm | 150mm |
speed | 15-30/min | 15-40/min | 15-40/min |
heating power | 80kw | 120kw | 150kw |
Main motor power | 4kw x 3 | 5.5kw x 6 | 7.5kw x 6 |
Sheet feeding motor power | 5kw | 5kw | 5kw |
Stacking power | 1kw | 1kw | 1.5kw |
Windin pmotor power | 0.55kw | 0.55kw | 0.55kw |
Total installed power | 100kw | 120kw | 180kw |
Gas consumption | 0.5-0.8 bar | 0.5-0.8 bar | 0.5-0.8 bar |
weight | 9ton | 15ton | 20ton |
Overall dimensions | 8x2.4x2.2m | 10x2.4x2.5m | 12x2.4x3.2m |
Warranty:1 Year Applicable Industries:Hotels, Garment Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Food Shop, Food & Beverage Shops
Key Selling Points:Easy to Operate Showroom Location:Egypt, Turkey, Germany, Viet Nam, Philippines, Brazil, Peru, Indonesia,
Pakistan, India, Mexico, Thailand, Argentina, Chile, Nigeria, Malaysia
PACKAGING & DELIVERY
Packaging Details: Stretchin film covered, Wooden pallets for easy loading
Port: NingBo Lead time:
Lead time:
Quantity(sets) | 1 - 1 | >1 |
Lead time (days) | 40 | To be negotiated |
CONFIGURATION LIST
PARTS NAME | ORIGIN |
Forming servo motor | ESTUN & TRIO |
Cutting servo motor | ESTUN & TRIO |
Punching servo motor | ESTUN & TRIO |
Magnetic Valve of Forming | Japan (SMC) |
Magnetic Valve | Airtac |
Cylinder | Airtac |
Feeding Servo Motor | ESTUN & TRIO |
Stacking Servo Motor | ESTUN & TRIO |
Voltage Regulating module | China Brand |
Temperature module | China Brand |
Heater | China Brand |
PLC | TRIO |
Touch screen | ESTUN & TRIO |
Encoder | Japan (Omron) |
Contactor | France Schneider |
Switch | France Schneider |
Breaker | Schneider |
MACHINE DETAILS
Forming Station
The forming station is the first critical stage in the Multi Station Thermoforming Machine, located immediately after the oven.
Once the sheet is heated by the oven, it enters this station, where it is expertly formed into the shape of the mold impression through precise stretch and air compression created between the molds.
Cutting Station
The cutting station, either the second or third station in the Multi Station Thermoforming Machine, utilizes a kick station in special cases.
This station ensures high accuracy and speed in cutting the molded sheet, enhancing the precision and efficiency of the multi station thermoforming machine for optimal production performance
Servo Drive
Our thermoforming machine, is equipped with Estun Servo Drives, renowned for their high accuracy and production efficiency.
Having utilized these servo drives for all our thermoforming machines, we have experienced flawless performance with no errors, showcasing their exceptional reliability and consistency in delivering high-quality results.
Servo
Our machine is equipped with Delta and Estun Servo Motors, ensuring high accuracy and production efficiency.
These reliable servo motors have been in use for the past 10 years without any errors, demonstrating their exceptional durability and performance in industrial applications.
Winding Motor
Our Multi Station Thermoforming Machine features a winding unit with a torque motor to efficiently collect waste sheets and wind them into a roll, which can be conveniently removed at the end of production.
This advanced waste management system enhances operational efficiency and cleanliness, making the multi-station thermoforming machine an ideal choice for high-quality and sustainable production.
PRODUCTS RANGE
The multi-stations thermoforming machine issuitable tohandle different materials, such asA-PET, R-PET, C-PET, BOPSHIPS, PP, PLA, PVCand barrier material and to producemanyitems: trays, lids, fruits and vegetablesboxes,fower pots,clamshells,nursery traysand plates.
It can make some products which unable to be made in one station thermoforminging machine, like for example: PLA products, plastic lids or containers which has holes, the packing containers (fruit box, egg trays) with body and cover connected etc.
EXHIBITIONS AND FAIRS
COMPANY PROFILE
Zhejiang Wylong Machinery Co., Located in Ruian,Zhejiang Provicne ,is 500kms,away from Shanghai. with 20 years of machinery manufacturing and selling is Plastic sheet extruder,thermoforming machine ,and multi-station thermoforming machine With ISO 9001 Certification,advanced technology and equipment ,as well as the R&D ability of new products,our products are sold all over the world and enjoy a high reputation at home and abroad ,Since its establishment the company adheres to the principles of "scientific management, high quality and efficiency ","customer first and credibility commitment",we always take consumers as our first consideration ,we insist on providing high-quality products and services ,and sincerely welcome new and old friends from all walks of life to visit us and create a better future.
QUESTIONS YOU MAY ASK
Q1: Do you have different models for each machine?
Reply: Yes, we have different models and we can make the machine according to your requirements.
Q2: What is the production time?
Reply: Normally we need around 45 days.
Q3: What service you can offer after we buy the machine?
Reply: We have a few experienced technicians who can help to install and test running the machine anytime overseas. Moreover, our own export personel will give you the service support after buying the machine. As long as you have any questions, we will try our best to help you.
Q4: Should the customer send the sample cups?
Reply: Yes, if there is. If the customer has no samples, please send a drawing or a photo of the sample, and let us know the size. Then we will send the drawing for your confirmation.
Q5: What about the payment terms?
Reply: We accept T/T. 30% as deposit and 70% balance should be paid before delivery. We can also accept 100% confirmed irrevocable L/C at sight.
Q6: What is the capacity of the thermoforming machine?
Reply: Working 20 hrs/day, the capacity is 300,000-500,000 pcs/day. The accurate capacity depends on the size and material of the products.
Q7: How much space it needs for the thermoforming machine?
Reply: 5 meters in length (if need stacking machine, require another 3.5 meters), 2.5 meters in width.
Q8: What kinds of products can the thermoforming machine produce?
Reply: It can produce all kinds of disposible plastic cups, bowls, plates, boxes, yogurt cups, plant pots, food container, etc.
Q9: What material can be used in the thermoforming machine?
Reply: PP/PS/PVC/PET. Thickness 0.3-2mm.
Q10: What is the requirements of the machine for the electricity?
Reply: It needs three phase four wire. The copper core cable should be big than 25 mm³, aluminium core cable should be bigger than 50 mm³.
Q11: What is the requirements of the machine for the air?
Reply: The output volume of the compressed air should be higher than 2.4 mm³/min. The pressure should be higher than 6 kgs.
Q12: What is the requirements of the machine for the water?
Reply: The displacement of the water should be higher than 1.5 m³/min, and the pressure should be higher than 2kg. The temperature should be between 30°-50 °.
>>
