US$0.96-8.97
|
500 Meters
(MOQ)
|
Basic Info.
Model NO.
SAE 100 R2AT 1/2"
Reinforcement
Strength Steel Wire
Quality
100% Quality Testing
Transport Package
Woven Bags
Production Capacity
800, 000merters/Month
Packaging & Delivery
Package Size
70.00cm * 70.00cm * 30.00cm
Package Gross Weight
10.000kg
Product Description
Product Description Product Description
OEM Factory wholesale 1/2 Inch Flexible Hose wrapped SAE 100R1AT Hydraulic Hose
Tube: Oil Resistant Synthetic rubber
Reinforcement: One or two four braid of high-tensile steel wire
Cover: Smooth/Wrapped
Temperature Range: -40ºC~+100ºC
Detailed Photos
DN | Hose I.D | Braids O.D | Hose O.D | Working Pressure | Burst Pressure | Minimum Bend Radius | Weight | Length |
Inch | MM | MM | MM | MPa | Psi | MPa | Psi | MM | Kg/m | Meter |
5 | 3/16 | 4.6-5.4 | 8.9-10.1 | | 25.0 | 3625 | 100.0 | 14500 | 89 | 0.20 | 50/100 |
6 | 1/4 | 6.2-7.0 | 10.8-11.4 | 12.7-13.5 | 22.5 | 3260 | 90.0 | 13050 | 102 | 0.25 | 50/100 |
8 | 5/16 | 7.7-8.5 | 12.5-13.1 | 14.6-15.4 | 21.5 | 3120 | 85.0 | 12325 | 114 | 0.31 | 50/100 |
10 | 3/8 | 9.3-10.1 | 14.5-15.1 | 16.7-17.5 | 18.0 | 2610 | 72.0 | 10440 | 127 | 0.36 | 50/100 |
13 | 1/2 | 12.3-13.5 | 17.7-18.3 | 19.8-20.6 | 16.0 | 2320 | 64.0 | 9280 | 178 | 0.45 | 50/100 |
16 | 5/8 | 15.5-16.7 | 21.1-21.7 | 23.2-24.0 | 13.0 | 1885 | 52.0 | 7540 | 203 | 0.52 | 50/100 |
19 | 3/4 | 18.6-19.8 | 24.6-25.4 | 26.9-27.7 | 10.5 | 1520 | 42.0 | 6090 | 241 | 0.65 | 50/100 |
25 | 1 | 25.2-26.4 | 32.1-32.9 | 34.6-35.4 | 8.8 | 1280 | 35.0 | 5075 | 305 | 0.91 | 50/100 |
31 | 1-1/4 | 31.4-33.0 | 40.8-41.6 | 43.3-44.1 | 6.3 | 914 | 25.0 | 3625 | 419 | 1.30 | 20/40 |
38 | 1-1/2 | 37.7-39.3 | 47.2-48.0 | 49.7-50.5 | 5.0 | 725 | 20.0 | 2900 | 508 | 1.70 | 20/40 |
51 | 2 | 50.4-52.0 | 59.9-60.7 | 62.4-63.2 | 4.0 | 580 | 16.0 | 2320 | 635 | 2.00 | 20/40 |
Product Parameters
Packaging & Shipping
Certifications exhibition photos
FAQ
1) Is Jintongda a factory or trade company? Factory built in 1999, turnover 100million RMB.2) How many countries have you exported to? For more than twenty.3) Do you accept OEM orders? Yes, we have our own trademark JTD and Looeit, also customized for OEM orders.4) How long to deliver? 15 days for 1x20'GP, 25 days for 1x40'GP 5) Before deliver, is there any test in your factory? Yes,we have pressure test, appearance test, length measure, routing inspection for 100% products.
>>
