| Items | Unit | Parameters |
| Whole performance of machine | Max.theo. concrete output | m3/h | 30 |
| Max.concrete throughput | m3/h | 15 |
| Charging volume | m3 | 0.56 |
| Discharging volume | m3 | 0.45 |
| Max.concrete pumping pressure | MPa | 10 |
| Distribution valve type | | S Valve |
| Concrete cylinder diameter×stroke | mm | Ф180×1000 |
| Hopper capacity | L | 400 |
| Outlet diameter | mm | Ф150 |
| Power system | Diesel engine model | | R4105ZD |
| Electrical engineering power | kW | 66 |
| Rotate speed | r/min | 1800 |
| Winding motor power | kw | Hydraulic motor |
| Stir the motorPower | kw |
| Water pump motor powe | kw |
| Hydraulic system | Circuit type | | Open circuit |
| Pumping system pressure | MPa | 32 |
| Mixing system pressure | MPa | 6-8 |
| Capacity of oil tank | L | 350 |
| The biggest transportation is away from vertically (/Level) | m | 90/400 |
| Other parameters | Max.aggregate diameter | mm | Scree: 30 |
| Inside diameter of delivering pipe | mm | Ф125 |
| Dimensions:length×width×height | mm | 6000x2300x3150 |
| Total weight | kg | 5000 |
