Warning globe is attached to the lines for warning.Warning area is between 25-40 meters.Warning globe is made of aluminum and is very light.Construction of the connectors provides easiness and safety to attach warning globe to the various lines.
Opearation
|
Visible Distance
| 1200mm
|
Voltage Range
| 35KV-1000KV
|
Conductor Diameter
| 6.5-55mm
|
Mechanical Structure
|
Color
| Orange,Red,White,Orange/White,Red/White
|
Sphere body
| FRP(Fiberglass Reinforced Polyester)
|
Cable Clamp
| Aluminum alloy
|
Bolts/Nuts/Washers
| Stainless steel 304
|
Diameter
| •300mm/400mm/600MM/800mm/1000mm/1200MM•340(Rotational)
|
Weight
| 6.9KG/9.0KG
|
Thickness
| 3mm
|
Drain Holes
| Yes
|
Optional
| •Prefromed Armor Rods •Reflective Strip
|
Warranty
| 2Years
|
