Product Description
Introduction
Dynamic Variable Optical Attenuator (DVOA) based on MEMS is an important component for power regulation in all-optical networks. DVOA can realize the full remote control of all optical network. The main applications are: preset optical power balancing, channel transmission balancing, optical automatic gain regulation, optical receiver protection, etc. The DVOA product developed by our company adopts MEMS control chip and unique optical design, which makes the product more miniaturized, lower cost, and more rapid response, with higher stability and reliability, and easy to manufacture.
| Features | Applications |
| High reliability | High transmission optical power |
| High stability | Optical path power balance |
| Low insertion loss | Channel transmission equalization |
| Rapid response | Optical automatic gain adjustment |
| small volume | Optical receiver protection |
| | optical path on &off |
Specifications
| Parameters | Unit | Index | Notes |
| Wavelength range | nm | 1260-1650nm or 980nm/1064nm |
| Attenuation type | | Normally bright or dark |
| Attenuation range | dB | ≥30 | |
| Max attenuation range | dB | ≥45 | |
| Insertion loss | dB | ≤0.8 (0.5 Typical) | Without the connector loss |
| Attenuation type | | Continue | |
| WDL | dB | ≤0.1 | 0dB test |
| ≤1 | 20dB test |
| Ripple wave | dB | ≤0.05 | 0.4nm Broadband is tested at 20dB |
| PDL | dB | ≤0.1 | 0dB test |
| ≤1 | 20dB test |
| TDL | dB | ≤0.15 | Test comparison at 0dB |
| ≤1 | Test comparison at 20dB |
| RL | dB | ≥55 | |
| PMD | ps | ≤0.5 | |
| Respond time | ms | ≤2 (1 Typical) | 10-90% optical power |
| optical power resistant ability | mW | 300 | |
| Driving voltage | VDC | 6V | Typical is 40dB at 5.2v |
| Power consumption | mW | ≤2 | |
| Operating temperature | ºC | 0 to 70 | |
| Storage temperature | ºC | -40 to 85 | |
Ordering information:
| ZG | VOA | Port | Operation wavelength | Fiber type | Fiber length | Connector |
| | 1=Normally close 2=Normally open | 0101=1X1 | 10=1060nm 13=1310nm 15=1550nm 16=1625nm X=Others | 1=Bare fiber | 1=1M | 0=None |
| 1=FC/APC |
| 2= FC/PC |
| 2=900um Optical fiber | | 3=SC/APC |
| 4=SC/PC |
| 5=ST |
| 6=LC |
| XX=Others | XX=Others | XX=Others |
Dimensions:
Linearity:
>>
