21.5 22 Inch Vandal-Proof IP65 Water-Proof Industrial Touch Screen Monitor

Product Description

21.5 22 Inch Vandal-Proof and IP65 Water-Proof Industrial Grade 21.5" Pcap Open frame Touch Monitor Strength & Advantage

Main Features
1. Open frame type, Shockproof& Dustproof &Waterproof IP65, Industrial grade
2. Custom design available without addtional cost.
3. Building 2*5W speakers
4. Touch screen : Capacitive
5. Working environment: -10°C ~60°C
6. Easily build-in any kind of display rack
7. Accessories: use manual, power adapter
More Specs
LCD screen specs	Model number	TD215-A01
	Screen size:	21.5"
	Display ratio:	16:9
	Resolution(Pixel):	1920*1080
	Display color:	16.7 M
	Response time :	5ms
	Luminance:	300 cd/m2 (higher brightness optional)
	Contrast ratio:	800:1
	View angle display(L/R/U/D):	89/89/89/89
Power supply	AC Input:	110-240V
Appearance	Color option:	Black or White optional
	Housing material:	Metal
	I/O interface:	USB port, VGA, HD input, Audio in/out
	Installation:	Build-in
	Unit dimensions:	394(W)×241(H)×34.8(T)mm
	Screen area:	344 * 194 mm (16:9)
	Product weight:	9KGS

LCD Screen specification
Original A level high quality screen

Screen Type	A-Si TFT-LCD back-light, A-type
Resolution	1920*1080P
Brightness	≥ 250 cd
Contrast ratio	≥ 1000:1
Viewing angle	89/89/89/89(Typ.) CR≥10) left/right/up/down

Product detail

Screen Type	LED LCD (A-Si TFT-LCD WLED backlight) A gauge
Size	21.5 inches (16:9)
Display area	477.6(W)*269.1(H)mm
The best resolution	1920*1080
Brightness	≥250cd/m 2
Contrast	≥ 3000:1
Response time	13/5 (Typ.)(Tr/Td) ms
Color Total	16.7M , 74% NTSC LVDS interface 30 Pins
Full viewing	Angle 89/89/89/89 (Typ.)(CR≥10)(left/right/up/down)
Service life	30000 hours
Refresh frequency	60Hz

Feature
1.Capacitive touch: 10-point projected capacitive touch technology, 5 ms fast response, accurate and stable;
2.HD display: new A gauge LCD screen, HD resolution, brightness ≥ 250cd/m2, clear and natural colors;
multi-system compatibility: touchwo can provide a single touch display, Android touch all-in-one, computer touch all-in-one machine;
3.new design, private model unique, pure flat slim structure, the thinnest point only 7mm, the total thickness of only 40mm;
4.New frame paste process, better display effect, better sealing, surface IP65 waterproof;
5.Aluminum alloy frame and mounting plate + baffle, stylish appearance, lighter than sheet metal products.
comprehensive use of corrosion and oxidation resistant sandblasting process, better durability, sheet metal backshell, better electrical conductivity;
6.Each machine is subjected to multiple tests such as whole machine aging, high and low temperature, static electricity, vibration, high pressure, and touch click to ensure more stable quality.
7.Support customization: provide a variety of customization services, flexible to add multiple serial ports, U-port;
(such as: appearance color, logo, camera, 4G module, card reader, fingerprint recognition, small ticket printer, QR code, etc.)
8.Easy installation: support wall / desktop / embedded and other installation methods, power on plug and play, no debugging.
MAIN PRODUCTS
Product Description
Packaging & Shipping

Company Information
FAQ FAQ
Q1: How is the quality?
A: Yes, equipped with high and low temperature tesing machine, vibrationi tester, all merterial are original guarantee, CE, ROHS, FCC, CCC, ISO9001 certificates passed.

Q2: What's the warranty of your power bank?
A: 12 Months.

Q3: Do you provide samples?
A: Yes, sample is available and in stock, can be sent out within 2 days.

Q4: What is the MOQ?
A: NO MOQ .

Q5: Can you print our logo?
A: Yes, OEM and ODM are highly welcome.

Q6: How to ship to us from your factory?
A: Optional: Fedex/DHL/UPS/EMS, by air, by sea or to your China forwarder.

Q7: How we send the payment to you?
A: We accept T/T, L/C

---
