| Main Specifications and Technical Parameter |
| Item | MMKC 1320E |
| Max diameter of grinding | 200 mm |
| Max Length to be ground | 500 mm |
| Max workpiece weight | 50 kg |
| Max travel of the table | 660 mm |
| Min feed of the table | 0.001 mm |
| Spindle hole taper | No.3 |
| Spindle Chuck | 125 |
| Tailstrok quil hole taper | No.3 |
| Min feed of wheelhead | 0.001 mm |
| Spindle speed | 60~460 mm |
| Max travel of wheelhead | 170 mm |
| Max linear velocity of wheelhead | 46 m/s |
| Grinding wheel size (Dxtxd) | 400x40x127 mm |
| Work pressure in hydraulic system | 0.8~1 Mpa |
| Flow rate of cooling pump | 25 L/min |
| Spindle motor | 0.23~0.37 kw |
| Grinding electric machinery | 4 kw |
| Total Capacity | 8 KVA |
| Over dimensions (LxxH) | 2400x1700x1800 mm |
| Weight of machine | 2800 kg |
| Work precision |
| Roundness | 0.001 mm |
| Diameters unanimity in section | 0.005 mm |
| The surface roughness (Ra) | 0.04 μm |
