Dakiou Zgj-D Paper Drink Tube Machine

Product Description

DAKIOU ZGJ-D Paper Drink Tube Machine
DAKIOU ZGJ-D Paper Drink Tube Machine, suitable for small diameter (6-12 mm) paper straw. It concludes 6 units: unwinding, gluing, stretching, twisting paper, cutting, and collecting. Different size of paper straw making can be fulfilled by changing the size of stainless steel core.

TYPE	ZGJ-D
Winding Speed	30-45 m/min
Suitable Material	Width and weight Surface paper-15mm ; 60g Middle paper-14mm 120g Bottom paper-13.5mm 120g
Number of roller	3 Layer
Tube	Diameter : 6-12 mm Wall-thickness: 0.3-1 mm
Cutting Length	100-800 mm
Cutter	5 sets
Twisting Head	2sets
Working Air Pressure	0.6 Mpa
Overall Dimension	5600 x1600 x 1750 mm
Working Space	11000 x6000 x 2000 mm
power source	380V //3Phase/ 50HZ
Weight	2000KGS

Machin Display:
Paper Straw Display:
Please feel free to contact with us:
Linda Lin

Youtube: https://youtu.be/PsPrB11K9h0

---
