Ck40p New Design Slant Bed CNC Turning Lathe Center with Live Tooling

US$23,000.00-45,000.00 1 Box (MOQ)

Basic Info.

Model NO.

CK40P

Type

Multi-Axis Automatic and Semi-Automatic Lathe

Processing Accessory

Centre CNC Lathe

Guide Rail

Vertical Linear Guide

Tool Holder

Single-tool Holder CNC Lathe

Power Source

Electric

Controlling Mode

CNC

Automatic Grade

Automatic

Setting Mode

Floor-type

Precision

High Precision

Certification

GS, CE, ISO 9001

Condition

New

Machine Name

Slant Bed CNC Lathe

Machine Type

Slant Bed CNC Turning Center

Machine Model

Ck40p Slant Bed CNC Lathe

Machine Specification

CNC Lathe with Live Tooling

Transport Package

Wooden Case with Iron Foot

Specification

1460x1570x2030mm

Trademark

Yuzhuo

Origin

Shandong

HS Code

8458110090

Production Capacity

400/Year

Packaging & Delivery

Package Size

1.00cm * 1.00cm * 1.00cm

Package Gross Weight

1.000kg

Product Description

CK40P New Design Slant Bed CNC Turning Lathe Center With Live Tooling
TCK40P Parameter

Model	TCK40P
Machine structure	45°
Guide type	Linear guide
Guide width	X axis 30 Z axis 30
Max swim over bed diameter	400mm
Max swim over carriage	150mm
Spindle nose to carriage length	400mm
X axis travel	720mm
Z axis travel	400mm
X axis fast move speed	12000mm/min
Z axis fast move speed	12000mm/min
Spindle type	A2-5
Spindle bore	42mm
Puller hole diameter	36mm
Spindle speed	4000r/min
Spindle motor power	4KW
Turret type	Gang type tool carrier 5 pieces
Tool size	20x20mm
Tail stock type	Without tail stock
Machine net weigth	1.8T
Machine size	2100X1600X1800
Accuracy
X axis reposition accuracy	0.006mm
Z axis reposition accuracy	0.006mm
Diameter uniformity	0.03/300mm
Flatness	0.03/300mm
roughness	0.8-1.6

Standard Configuration
GSK928 CNC Controller, X Z servo motor and driver
With gang tools post for 4 pieces
Hydraulic collect with hydraulic station and cylinder
Frequency main motor
Auto lubrication system, cooling system, lighting
380v 50hz 3phases
Option:
GSK980, SIEMENS CNC
Hydraulic chuck 6inch
Servo main motor
4 or 8 station electric tool turret
Auto bar feeder oil bath type 3meter,
Chip conveyor
Finished parts collector.
