Product Details
Product Description
Product Description
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands
N.132-18N.143-18 IB3110050
The support arm may be placed on either side of the ventilator to support the patient breathing circuit. To connect to the ventilator, place the post into the arm holder and tighten the thumbscrew. Do not exceed 2 kg load at the patient end of the support arm. Do not hang fluids on the support arm above the ventilator or accessories. The support arm is not a sterile component and cannot be autoclaved or immersed in cleaning solution. 1. Loosen the thumbscrew. 2. Place post in the arm holder located on the back of the ventilator. 3. Tighten the thumbscrew to hold the arm in position. 4. To position the arm, loosen the central tension handle counterclockwise while holding the patient side of the arm in the other hand. There is a stop to prevent the central tension handle from being completely loosened. 5. Move the arm to the desired position. 6. Tighten by turning the central tension handle clockwise. WARNING CAUTION Important 4 Setup and connections 2065490-001 4-33 AB.100.178 3 1 2 Figure 4-12 • Support arm installation 1. Thumbscrew 2. Support arm holder 3. Central tension handle CARESCAPE™ R860 4-34 2065490-001 Removing the display unit A movable part or a removable component may present a pinch or crush hazard. Use care when moving or replacing system parts and components. The display unit is top heavy when removed from the ventilator. 1. Power down the ventilator and lock casters if using the ventilator cart. 2. Position the display arm so that it is vertical and the display unit so that it is horizontal (screen facing up). 3. Firmly hold the display unit at the junction of the display arm and display screen. 4. Open the primary latch (1). 5. Pull and hold the secondary latch (2) toward the front of the arm assembly to disengage the display unit. 6. Carefully lift and remove the display unit from the ventilator.
>>
