US$10,000.00
|
1 sets
(MOQ)
|
Basic Info.
Paper Core Usage
Industry
Processing Type
Winding Machine
Dimension(L*W*H)
5600*2250*2170mm
Showroom Location
Egypt, Canada, United Kingdom, Viet Nam
Warranty of Core Components
1 Year
Video Outgoing-Inspection
Provided
Applicable Industries
Hotels, Manufacturing Plant
Marketing Type
Ordinary Product
Core Components
PLC, Motor
Product Type
Paper Core Machine
Voltage
380V / 3phase / 50Hz (Can Be Customized)
Application
Paper Tube Core Production
Machinery Test Report
Provided
Transport Package
Seaworthy Packing (Wooden Case / Pallet)
Production Capacity
30 Set/Sets Per Month, 1-30m/Min.
Product Description
Product Description CFJG-30 Multi-cutter tube & core making machine equipped with Numerical and Multi-blades Cutting System. Suitable for toilet paper core; preservative film etc.
--Synchronous cutting system controlled by servo motor -- it means the cutting part moves together with paper tube and cutting in a high precision.
-- Adopt with MULTI CUTTERS and inline cutting length reaches to 70-1400mm. Paper tubes can be finished in one time.
Technical Parameters
Technical Parameter
| Control System
|
Paper Layer
| 12 layers
| PLC
| Xinjie
|
Inner Diameter
| 25-100mm
| Man-machine Interface
| Touch Screen (Xinjie)
|
Wall Thickness
| 1-5mm
| Inverter
| 7.5KW Delta (Taiwan)
|
Winding Speed
| 0-20 meters/min
| Execute Components
| CHNT
|
Winding Nose
| Two noses single belt
| Signal Components
| Hugong
|
Shaft Fixing Way
| Flange
| Pneumatic Components
| Jingwei
|
Cutting System
| Numerical Multi-blades (standard 5 pcs)
| Electric Components
| CHNT
|
Synchronism tracking cutting system
| Servo motor synchronism
| Bearing
| Haerbin
|
Servo Motor
| 1.3kw Yaskawa (Japan)
|
Gluing Way
| Single / Double (can be chose)
| Screw Rod
| ABBA
|
Length fixing
| Encoder
| Slider
| ABBA
|
Operator
| 2-3 persons
| Configuration
|
Speed Control
| By Inverter
| Paper Reel Stand
| 10 Layers Integral Type
|
Power Supply
| 380V/3Phase/50Hz (can be customized)
| Gluing System
| 10 Layers Spraying Type
|
Size
| Inner Paper Shelf
| 1 Set
|
Mainframe(two parts)
| 5600*1600*1750mm | Surface Paper Shelf
| 1 Set
|
Mandrel Shaft
| 1 Piece (Size to be provide by buyer)
|
Working Space
| 10000*6000mm
|
Weight
| 3200kgs
| Belt
| 2 Pieces
|
Driving System
| Belt Adjusting
| Manual
|
Main Motor
| 5.5KW Wannan
| Adjusting of paper reel stand & gluing shelf
| Automatic
|
Motor Rotating Speed
| 1400r/min
| Automatically Gluing
| Gluing Pump 1.5kw
|
Nose Rotating Speed
| 48r/min
| Lubricating Oil for Paper Tape
| Automatically Supply
|
Nose Output Strength
| 1000N.m
| Enclosed Spare Parts
|
Reduction Box
| WPO135
| Mandrel Shaft
| 1 Piece
|
Gear Box
| WPO135
| Useful Tool
| 1 Set
|
Driving Chain
| 16A*2
|
|
|
Pictures Hot Sale Multi Knives Servo Controlled Paper Core Tube Making Machine
Multi-knives Online Cutting System (cutting length 100-1200mm; controlled by servo motor)
Double Heads / Single Belt Spiral Winding
Equipped with 10 Layers Integral Type of Paper Reel Stand
Equipped with 10 Layers Soaking Type of Glue Stand
Machines in Cutomers' Facility
Finished Products
