US$25.00-50.00
|
10 Pieces
(MOQ)
|
Basic Info.
Application
Double Beam Crane, Gantry Crane, Bridge Crane, Tower Crane, Single Grinder Crane, Lifting Platform, Small Crane
Maximum Lifting Height
3m
Certification
CE, ISO9001:2000, GS
Transport Package
Wooden Case
Production Capacity
10000/Year
Product Description
Shuangge Brand HS Type 5 Ton Classic Round Chain Block
Model | Capacity (t) | Standard lift(m) | Running test load | Headroom (mm) | Load chain | Effort required to lift max load(N) | Main Dimensions(mm) | Packing measurement (cm) | Extra weight per meter of extra lift(kg) | Gross weight (kg) | Net weight (kg) |
Columns | Dia (mm) | A | B | C | D |
HS0.5 | 0.5 | 2.5 | 0.75 | 240 | 1 | 6 | 221 | 120 | 108 | 24 | 120 | 28x21x17 | 1.7 | 10 | 8 |
HS1 | 1 | 2.5 | 1.5 | 270 | 1 | 6 | 304 | 142 | 122 | 28 | 142 | 30x24x18 | 1.7 | 13 | 10 |
HS1.5 | 1.5 | 2.5 | 2.25 | 347 | 1 | 8 | 343 | 178 | 139 | 34 | 178 | 34x29x20 | 2.3 | 20 | 16 |
HS2 | 2 | 2.5 | 3 | 380 | 2 | 6 | 314 | 142 | 122 | 34 | 142 | 33x28x19 | 2.5 | 17 | 14 |
HS3 | 3 | 3 | 4.5 | 470 | 2 | 8 | 343 | 178 | 139 | 38 | 178 | 38x38x20 | 3.7 | 28 | 24 |
HS5 | 5 | 3 | 6.25 | 600 | 2 | 10 | 381 | 210 | 162 | 48 | 210 | 45x39x24 | 5.3 | 45 | 36 |
HS8 | 8 | 3 | 10 | 700 | 3 | 10 | 392 | 356 | 162 | 64 | 210 | 62x50x28 | 7.3 | 70 | 58 |
HS10 | 10 | 3 | 12.5 | 700 | 4 | 10 | 392 | 358 | 162 | 64 | 210 | 55x51x29 | 9.7 | 83 | 68 |
HS16 | 16 | 3 | 20 | 820 | 6 | 10 | 392 | 400 | 196 | 69 | 210 | 68x60x34 | 14.1 | 127 | 112 |
HS20 | 20 | 3 | 28 | 1000 | 8 | 10 | 392 | 580 | 189 | 82 | 210 | 70x46x75 | 19.4 | 193 | 155 |
Self-manufactured superior G 80 load chain,DIN standardDrop-forged and heat treated load hooks with safety latchs and hook holdsDouble pawls brake systemNon-Asbestos brake discsHigh grade sealed roller bearings100% Running load test is 1.5 times of rated capacityThe static load test is 4 times of rated capacityMore than 1500 cycles of fatigue test at 1.5 times of work loadOverload limiter can be adopted at your requestOEM service can be provided
FAQ: 1. Q:Why Choose Wuyi?
A:Wuyi established in 1972,more than 40 years experience in the chain hoist field with professional technical team.
2. Q:Can I have samples to test?
A:Ready samples can be provided to you to check the quality and test.
3. Q:Guarantee
A:One year
4: Q:OEM service
A:Shuangge is our own brand,OEM also can be provided.
>>
