| US$5,000.00-6,000.00 | 1 Piece (MOQ) |
| Specifications | CA6140 | CA6150 | CA6161 | CA6166 | CA6180 | |
| Max. Work piece Diameter of Bed | 400mm | 500mm | 610mm | 610mm | 800mm | |
| Max. Work piece diameter of tool holder | 220mm | 300mm | 370mm | 370mm | 540mm | |
| Max.Work piece Length | 750/1000/1500/2000/2200/3000/4000mm | |||||
| width of bed | 400mm | |||||
| Cutter rod section | 25×25mm | |||||
| Spindle axis | Spindle speed range | 16-1400rpm(24steps) | ||||
| Spindle bore | 52mm ,(80mm),[105mm] | |||||
| Mores | No.6(MT6)(Φ90 1:20)[Φ113:20] | |||||
| feed | Feed Quantity | (64 kinds)(for each) | ||||
| Metric thread | (1-192mm) (44 kinds) | |||||
| English thread | (1-24tpi) (21kinds) | |||||
| Modular thread | 0.25-48(module 39 kinds) | |||||
| Diameter thread | 1-96DP(37 kinds) | |||||
| Tailstock | Tailstock spindle travel | 150mm | ||||
| Tailstock spindle diameter | 75mm | |||||
| Taper of tailstock spindle hole | Morse NO.5 (MT5) | |||||
| Main motor | 7.5KW(10HP) | |||||
| Package dimensions | length 750mm | 2440×1140×1750 | ||||
| length 1000mm | 2650×1140×1750 | |||||
| length 1500mm | 3150×1140×1750 | |||||
| length 2000mm | 3650×1140×1750 | |||||
| length 2200mm | 4030×1140×1750 | |||||
| length 3000mm | 4800×1140×1750 | |||||
| length 4000mm | 4800×1140×1750 | |||||
| weight | Length | G.W./N.W.(KG) | ||||
| Length 750mm | 2170 /2060 | |||||
| Length 1000mm | 2260/ 2140 | |||||
| Length 1500mm | 2420 /2290 | |||||
| Length 2000mm | 2790/ 2640 | |||||
| Length 2200mm | 2940/ 2790 | |||||
| Length 3000mm | 3450/ 3300 | |||||
| Length 4000mm | 3750/ 3600 | |||||
