Yse-010 1/4′ 3/8′ Stainless Steel IP65 AC230V High Pressure Low Power Electromagnetic Solenoid Valve 300bar

US$22.00 50 Pieces (MOQ)

Basic Info.

Model NO.

YSE-010

Actuator

Electric

Connection Form

Thread

Type

Direct Acting

Material

Stainless Steel

Pressure

High Pressure

Valve Structure

Pilot Piston Structure

Power Supply

AC/DC

Usage

Safety, Emptying, Drain, Temperature Control, Flow Control

Application

Industrial Usage, Water Industrial Usage, Household Usage

Structure

Control

Customized Support

OEM, ODM, Obm

Port Size

1/4"~ 1", 1/4", 3/8", 1/2", 3/4", 1"

Warranty

1 Years

Voltage

DC12V, 24V AC110V, 220V

Thread

NPT BSPT PT BSPP

Orifice

1.0, 1.5, 2.0, 2.5, 3.0, 10, 15, 20, 25

Transport Package

1. Logo Standard Cartons 2.White Carton Box Withou

Trademark

Jery

Origin

China

Production Capacity

50000 Piece/Pieces Per Month

Product Description

Technical parameters Working medium:liquaid,ai,light oil(viscosity≤20cst)
medium temperature: 0 ~ 80ºCWorking pressure: 0~300bar(see specification table) enviroment temperature:-10 ~ 60ºCValvebody material:SS304 working type:DN1~5 direct acting ,DN10~25 pilot operatedInterface:G thread ,NPT thread sealing material:PTFEWorking voltage:ES low power coil AC220~240V,AC110V 50/60Hz 7VA , DC24V 6W . IP65,H degree. Other voltage can be customized. option: Nass coil ,LED light connector , timer ,Rc thread.
