Double Horizontal Shaft Complusory Mixer Js500

Product Description

JS500 Double Horizontal Shaft Compulsory Mixer Welcome to the future of construction with our Heavy-Duty Concrete Mixer. This state-of-the-art machine is designed to meet the demands of modern construction projects, offering a blend of power, efficiency, and reliability. Whether you're working on a small residential development or a large commercial project, our mixer is up to the task. Our mixer is not just a tool; it's a partner in your construction journey. With its robust construction and high-capacity drum, it ensures that you have a consistent supply of high-quality concrete, reducing downtime and increasing productivity.
Technical Features
-Features:
1.Equipped with multiple shaft end seal protection devices and wind pressure seal protection devices to effectively prevent leakage;
2.Unique mixer monitoring system can monitor the working status of the reduction box, discharge pump, and electric lubricating oil pump at any time;
3. Equipped with a pressurized upper cover water discharge system, the spraying area is larger and the water discharge is more uniform
4. Equipped with a DC24V centralized lubricating oil pump for concrete mixers, the running time can be programmed independently, it is waterproof, dustproof and has excellent performance;
5. Equipped with an enhanced reduction gearbox, and processed with high-precision technology, it has strong load capacity and longer service life;
Equipped with high-quality high-wear-resistant alloy stirring arms, the service life is 3-5 times that of ordinary stirring arms;
-Applications:
:lt is more suitable for mixing medium & large aggregate particle size. Technical Parameters

Type	LJB350	JS500	JS750	JS1000
Charging Volume(L)	560	800	1200	1500
Discharging Volume(L)	350	500	750	1000
Productivity(m³/h)	≥17.5	≥25	≥37.5	≥50
Max. Grain Size of Aggregate(mm)	60	60	60	60
Speed of Mixing Blade(r/min)	35	35	32.6	32.6
Mixing Blade(PCS)	3	14	14	16
Model of Mixing Motor	Y112m-4	Y180m-4	Y200L-4	XWDY9-17-185-6P
Power of Mixing Motor(KW)	5.5	18.5	30	18.5x2
Model of Winch	JS350	JS500	JS750	JS1000
Power of Winch(KW)	4.5	5.5	7.5	11
Height of Unloading Material(mm)	1200	1500	1600	2080
Model of Water Pump Motor	252B21-0.37	252B27-0.75	65JDB-30	KQW65-100
Power of Water Pump Motor	370w	750w	1.1KW	1.5KW
Frame Dimension in Working Condition(mm)	3618×1222×3453	4461×3050×5225	4950×3636×6530	7922×3510×6064
Transporting Frame Dimension(mm)	1721×1222×2450	3050×2300×2500	4150×3636×2500	4200×3110×2780
Net Weight(T)	2	4	6.8	9

---
