| Model Number (Engine Type) | PLG-XXGF(Cummins,Weichai,Ricardo,MAN) |
| Prime Power/Standby Power | 10kW-1200kW |
| Rated Speed | 1500/1800RMP |
| Rated Frequency | 50/60Hz |
| Rated Voltage | 400V/230V |
| Phase | AC 3-Phase, 4 wire |
| Gas consumption | 24m3.kw/h |
| Starting System | DC 24V electric motor |
| Cooling method | Water-cooled |
| Alternator | Faraday,Leroy Somer, Stamford |
| Exciting method | Brushless |
| Controller Type | Auto PLC Controller |
| Controller Brand | Deepsea, SmartGen, ComAp, etc. |
| Application | Mines, building, oil fields, hospitals, ports, schools, hotels, etc. |
| Gas requirements | 1. The gas does not contain free water or other free substances (impurity particle size should be less than 5μm). 2. The alkane content is not less than 55% (volume percentage), and the calorific value of the gas is required to be ≥ 5500 kcal/m3. Decrease in unit power if low calorific value fuel (calorific value ≥ 1100 kcal/m3) is burned. 3. Gas pressure 2-10kpa. 4. The sulfur content is not more than 20ppm, and the sulfur content should be removed for excessive sulfur impurity gas. |
