Eco-Friendly Honeycomb Paperboard Production Machine for Sustainable Packaging

US$530,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
HX2600-1100G
Condition
New
Certification
ISO 9001:2000, CE
Automation
Automatic
Suitable for
Recycled Material, Paper
Paper Thickness
Normal Specification Paper
Material
Starch/PVA
Heating
Steam
Opearting Person
3
Production Time
5month
Transport Package
5 40hq
Specification
35300mm *6000mm *3800mm
Trademark
Meixun
Origin
China
Production Capacity
10 Sets/Year

Product Description

Product Description
parameters Specifications
1 Effective width of core paper 1300mm-2600mm
2 roll diameter) φ1400mm
3 Core paper weight 80g/M²-150g/M²(Medium to high strength corrugated paper)
4 Adhesive Starch glue,PVA
5 Finished paper core thickness 5-60mm
6 Honeycomb paper core cross-cut production speed 1100cuts/min(Thickness6mm,paper core weight90-120g)
7 Honeycomb hole side length To be determined
8 Honeycomb flatness ±0.1mm
9 Heating method Steam heating
10 Equipment installed power Approximately50KW
11 normal production power consumption 50KW*50%-60%
12 Total weight of equipment Approximately80T
13 Equipment dimensions 35300mm length×5600mm width×3800mm high
14 Equipment operation direction To be determined

Main technical parameters of the equipment: Experience the sheer excellence of our equipment, designed with meticulous precision to meet high standards. From energy-efficient operation to robust construction, every technical aspect is crafted to ensure reliability and superior performance. Dive into a world where advanced technology meets unparalleled functionality.
2600 paper core machine project configuration table
part name project Remark
1 Core paper unwinding unit Hydraulic Shaftless Paper Holder
(with simple paper changing Components)
2 aisle on the platform Rack Transition Parts
3 Core paper gluing unit Core paper gluing parts ( can be equipped with double- toothed rollers)
4 Core paper composite drying unit Single group ( can be equipped with double pressure rollers) composite traction parts , equipped with 2 groups of composite drying
5 Cross cutting machine unit High-speed cross-cutting machine parts
6 Paper core automatic collection unit Finished paper core automatic collection part
7 heating method steam heating
8 Main control component brand Mitsubishi, Inovance, Lenze
