US$58,000.00-60,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Application Area
Flooring Board
Mixing Drum Shape
Conical
Operating type
Cycle Operating
Transport Package
Small and Important Parts Packed with Plywood Case
Production Capacity
300pieces/Year
Product Description
Equipment parameters
No. | Item | Parameters |
1 | Working Condition | 380V/3P/50Hz (or customization) |
2 | Processing Material | PVC, Calcium powder mixed material |
3 | Mixer Unit Model | SRL-W1000/3000 |
4 | Mixer negative pressure transfer speed | 1.75T~2T/h |
5 | Vacuum pump power | 11KW |
6 | (Hot Mixer)Total volume | 1000L |
7 | Effective volume | 700L |
8 | The largest feeding amount at one time | 350-400 |
9 | Spindle speed | 0-600r/min |
10 | Mixing time/batch | 10-12min |
11 | Discharging method | Pneumatic |
12 | Heating method | Friction Heat |
13 | Material temperature | 110ºC |
14 | Discharge compressed air pressure | 0.49Mpa |
15 | Feeding holes | 4*Ø300 |
16 | Straight diameter of the discharge port | φ250 |
17 | Temperature measurement method | K-type thermocouple-temperature controller |
18 | Motor | 160kw inverter control |
20 | (Cold Mixer)Total volume | 3000L |
21 | Effective volume | 2000L |
22 | The largest feeding amount at one time | 500KG |
23 | Output | 2000KG/h |
24 | Spindle speed | 60r/min |
25 | Mixing time/batch | 8-10min |
26 | Heating method | Water cooling |
27 | Material temperature | 50ºC |
28 | Temperature mesurement method | K-type thermocouple-temperature controller |
29 | Compressed air pressure for discharging | More than 0.49Mpa |
30 | Number of feeding holes | φ300 |
31 | Motor | 30kw |
32 | Raw material storage bin | 3 m³ |
33 | Mixer feeding method | Vacuum feeder |
34 | Storage bin feeding method | Screw feeder |
Product Description Mixing Machine for SPC Flooring Production Line The PVC mixer unit is for mixing PVC powder, CaCO3 and other additives. This equipment is widely used in PVC
sheet production and profile production.The high speed PVC mixing machine is composed of plastic mixer (hot mixer),
cooling mixer and control cabinet. It will guarantee the mixer could use for long time under the high friction.The mixing
blades are passed the static and dynamic balance testing. And the main shaft adopts fine sealing to prevent material
leakage. Equipment details list
About Us HALLMARK INTERNATIONAL GROUP LIMITED HallMark is a professional manufacturer in flooring industry with 15 years experience,have own factory and richexperience.Products are sold to more than 50 countries around the world,suchas Russia, Turkey, Egypt, Algeria,
South Africa,Iran,India,Malaysia,Vietnam.
The main products of our company are laminated flooring and SPC flooring production line, and othernon-standard
customized equipment in the construction/wall panel/furniture industry.We can not only provide the above production
lines, but also provide a complete set of solutions and technical consulting services.
We provide one-stop supply and service for you ,from the raw material to machine design ,production,installation,commissioning,staff training, and after-sales service,also provide the turnkey solution. To provide customers with high-quality products,reasonable prices,timely and professional services to meet the various needs of
customers. HallMark firmly believes that transaction is not the end, but the beginning of service.
Packing and delivery
Certifications
Exhibition experience
FAQ 1. Rich experience and professional design
We have 15 years experience in flooring industry,also has many years exporting experience. Each equipment
location,passage will be designed reasonably to meet safety production.
2. Competitive price
HallMark has own factory,with the same configuration,the price is competitive.And we are familiar with the Chinese
market,our suppliers provide high-quality cost-effective accessories.
3. Timely after-sale service
We have over 15 skilled technicians offer after-sale service, will be sent to the customer's factory to assist in the
installation and debugging of the flooring production line until it runs well,and asked for quick responses to customer
questions within 8 hours. 4. One-stop solution
HallMark provide one-stop service, including market analysis and professional technical consultation,whole SPC
flooring production line, raw materials ,equipment installation, personnel training,Professional after-sales service
team,Renovation of old equipment,make turnkey projects.
5. Quality control
Strict quality control of equipment in production and before leaving the factory, and a complete quality management
system for purchased parts.Customers are always welcome to make videos or come to the factory to know the production
status.
6. Customized
HallMark's engineer team will design the layout according to customer's factory space and production requirements.
>>
