| PCB Item | Standard | Advanced |
| Layer Counts: | 1L--10L, HDI | 10L-18L,HDI |
| Base Material: | CAM1,FR4,F4BK,Arlon,Rogers |
| Material Suppliers: | GUOJI(GDM), KINGBOARD(KB), SHENGYI,Arlon |
| Material Thickness(mm): | 0.40, 0.60, 0.80, 1.00, 1.20, 1.50, 1.60, 2.0, 2.4, 3.2 |
| Max board size(mm): | 1200x400mm | 1200x500mm |
| Board Outline Tolerance: | ±0.15mm | ±0.01mm |
| Board Thickness: | 0.4mm--3.2mm | 0.3mm----3.2mm |
| Thickness Tolerance: | ±8% | ±5% |
| Minimum line/space: | 0.1mm | |
| Mini Hole Size(mechanical): | 0.2mm | |
| Innerlayer Copper Weight: | 0.1mm | |
| Innerlayer Copper Weight: | 17um--105um | |
| Outlayer Copper Weight: | 17um--105um | |
| Mini Solder Mask Bridge: | 0.05mm | |
| Impedance Control Tolerance: | ±10% | |
| Contours: | Scored, Routed, Punched |
| Surface Finishing: | HAL,lead-free HAL,ENIG,Plated Gold,Immersion Silver,OSP |
| 1--2L Lead Time: | 3-7 days |
| 4--18L Lead Time: | 7-15 days |
| Acceptable File Format: | Gerber file,Powerpcb,CAD,AUTOCAD,ORCAD,P-CAD,CAM-350,CAM2000 |
| Quality Standards: | IPC-A-600H Class2 |
| Certificate: | ISO9001:2008,PCB Assembly Capability |
