Filter Press System

Product Description

Product Description
Filter Press System
For some international and large readymix companies, they need clean water as well as aggregates, and it is not allowed to reuse the slurry water in the batching plant. Introducing from Australia technology, UDO designs and develops the filter press system in order to solve the treatment of slurry water. Dry cakes and normal clean water can be recycled through this system which realize “Zero Waste”, “Zero Discharge” and make the batching plant green.
Advantages
1. All the filter plates are made of totally new polypropylene.
2. The water is clean and the mud cake has low moisture content.
3. The filter press has an automatic flap device.
4. The filter mud is unloaded by a plate pulling trolley.
5. An electric three-way valve is installed by the water channel. When working normally, the clean water is discharged into the clear water tank. When the filter cloth is cleaned or the water is discharged abnormally, the valve is used to discharge the slurry water into the slurry tank to ensure that the slurry does not flow into the clean water tank.
6. Large amount of discharged water（High pressure type）
What is a Filter Press and How Does it Work
A filter press is a device used for separating solids from liquids. It is a piece of equipment that is commonly used in various industries such as pharmaceuticals, food and beverage, chemical manufacturing, and wastewater treatment plants.
The basic design of a filter press consists of a series of plates with filter media, such as cloth or paper, that are arranged in a vertical stack. The plates are pressed together using a hydraulic or mechanical mechanism, which creates a sealed chamber between them.
The process begins by feeding a slurry, or a mixture of solids and liquids, into the filter press. The liquid portion of the slurry passes through the filter media and is collected in a collection tank or reservoir. The solid portion of the slurry, or the filter cake, is retained on the filter media and is removed from the filter press.
The filter cake is then washed with additional water or other cleaning solutions to remove any remaining liquid or impurities. The washing process can be repeated multiple times to ensure complete removal of all solids.
Once the washing process is complete, the plates are separated, and the filter cake is removed from the filter press. The plates are then ready to be used again for the next filtration cycle.

---
