Electrochemical Autoclave Reactor

Product Description

Electrochemical reactors, also known as electrocatalytic reactors or electrosynthetic reactors, can be used for chemical and chemical high-pressure synthesis or electrocatalytic reactions to determine temperature, rotational speed and add inert gas, level pressure and achieve online sampling requirements for high-temperature and high-pressure electrocatalytic and photocatalytic environments at different pressures or temperatures with current and voltage reactions.Product Description
Kettle Body Part
1.Electrochemical reactor effective volume: 25ml (built-in with two working electrodes and one PTFE liner); one set of 316L high pressure reactor.
2.Design pressure: 40Mpa; working pressure: ≤30Mpa; (can be customized according to customer requirements)
3.Design temperature: ≤300ºC; working temperature: ≤250ºC; (can be customized according to customer's requirements)
4.The kettle is equipped with multi-functional air inlet, air outlet, feed, electrode replacement fixture, etc.
5.Electrochemical reactor with online sampling function.
6.TKA adjustable intelligent monitoring safety relief valve (safety relief accuracy ±0.1Mpa).
Heating and Stirring
1.Magnetic speed: 0-2500 rpm (digital display adjustable accuracy ±1) with 0-9999 minutes timing function.
2.Sealing method: magnetic seal plus metal hard seal (magnetic static seal effectively ensures zero gas leakage)
3.Heating method: 800W ceramic electric heating
4.Stirring form: magnetic stirring, driving power 60 watts.
Control Part
1.Temperature control: PID control temperature control (digital display), temperature control accuracy ±1. with timing function.
2.Rotational speed control: 0-2500 rpm (digital display), accuracy ±1/min.
3.Time control: 0-9999 minutes (can work timer setting)
4.Safety control: the whole machine with power failure start/stop protection function. (Experimental data can be automatically repaired record)
5. applicable power supply: single-phase 220V±10%, 50Hz.
Product Configuration
1.Valve: American Anrock (SS-OVM2-SH)
2. PTFE reaction cell set, working electrode power supply set
3.Light source workstation (optional)
4. pressure gauge: maximum display value 10Mpa using shockproof design, minimum display value 0.1Mpa, choose TKA brand anti-pressure and shockproof gauge. Digital pressure gauge is optional
5. safety valve using TKA intelligent safety valve, pressure relief range can be freely adjusted according to the experimental conditions, pressure relief accuracy ≤ 0.1Mpa
6.One set of stainless steel dismantling spanner, one set of moving handle, one set of fast cooling bracket, one intermittent sampler, one high pressure hose with special link for gas cylinderPackage&Shipping
Package Detail
1) Wooden packing
2) The goods can be shipped by sea, air or train, small goods or spare parts will be shipped by express.
3) You can choose your own freight forwardwe as well.
4) Door to Door Delivery to save your energy and time. We'll take the all risks during transportation.
Shipping Details
1) AMERICA:3-8 working days.
2) ASIAN:3-8 working days.
3) EUROPE:5-10 working days.
4) OCEANIA:4-9 working days.
5) AFRICA:7-13woring day.
Company Profile
Xi'an Taikang Biotechnology Co., Ltd, is a famous manufacturer of Lab equipment located in the central China. Now has TAIKANG, TKA two well-known brand trademarks. The main products include ultra-high temperature and high pressure reactor, high pressure photochemical reactor, supercritical high pressure reactor, high pressure glass reactor, micro high pressure reactor, high pressure ultrasonic reactor, Ultra-high temperature hydrothermal synthesis reactor, photocatalytic reactor, visual catalytic reactor, hydrothermal synthesis reactor, rotary evaporator, parallel synthesis reactor, high and low temperature circulator, high and low temperature high pressure tubular reactor and other equipment and so on.
Specialize in this field for more than 20 years,TKA brand instrument has own high reputation in more than 70 countries and regions, provide technical support for tens of thousands organizations to solve problems within their research, special for university, research institutes, industries, inspection agencies, etc. Promoting technology progress and improving human life is TKA social mission.
We welcome new and old customers from all over the world to contact us for future business relationships and achieving mutual success!! Exhibition Show
Certifications
FAQ
Q1:Are you trading company or manufacturer?
A1:We are professional manufacture of lab equipment and we have our own factory which is a high-tech enterprise integrating R&D, production and sales. And welcome to visit our factory.
Q2: How long is your delivery time?
A2: Usually, delivery time is 30-45 days after receiving your payment.
Q3:How to shipping the replacement parts?
A3:We will according the actual situation to choose the suitable shipping ways. For small parts we shippin by Express.
Q4: How about your quality warranty ?
A4: Normally all TKA products are supplied with a warranty of 12 Months from the date of shipment.
Q5: Do you accept OEM and ODM orders?
A5: Yes,We accept.
Q6:What is your terms of payment?
A6:Payment≤15,000USD, 100% in advance. Payment≥15,000USD, 70% T/T in advance, balance before shipment.
(If you are concerned about payment security for the first order, we advise you can place Trade Assurance Order via Made in China. you will get 100% payment refund if we can't meet agreed delivery time.)
Q7:Can we visit your factory?
A7: Welcome visit our factory.

---
