Dcmc Double Column Machining Center, Machine Lathe

US$50,000.00-100,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
SP1525II SP1530II SP1540II SP1830II SP1840II SP185
Precision
High Precision
Certification
GS
Condition
New
Transport Package
Woodencase
Specification
7900*6000*5000 8800*6000*5000 10800*6000*5000 8800
Origin
China
Production Capacity
1000pic/Year

Product Description

Product Description

01


02



03



04

Oil skimmer


Chain type chip conveyor

Screw type chip conveyor

Level gauge



Doors on both sides


05

Optimum ladder design of beam and saddle make the spindle center always vertical to worktable, with larger ram contact surface that improve the machine rigidity.
Double balance counterweight design eliminates bending of ram guideway when move up and down. It keep the high stability and accuracy of machine.



06





07


08

Equipped with heat exchange, which can cool electrical cabinet during working.
AC of cabinet is optional.

FANUC/SIEMENS/MITSUBISHI
Electrical cabinet hanging design reduced risk.

Spindle
Spindle taper : BT50
SP10 to 18 series are standard with belt typ
SP22 and SP25 series are standard with gear hea
Direct type, gear box and gear head only available from SP13 series and above
Product Parameters

 SP1525II SP1530II SP1540II SP1830II SP1840II SP1850II
SP2030 SP2040 SP2050 SP2060 SP2530 SP2540 SP2550 SP2560
Working range
X X axis travel mm 2600 3100 4100 3200 4200 5200
3200 4200 5200 6200 3200 4200 5200 6200
Y Y axis travel mm 1900 1900 1900 2400 2400 2400
2800 2800 2800 2800 3600 3600 3600 3600
Z Z axis travel mm 800 800 800 1000 1000 1000
1000 1000 1000 1000 1000 1000 1000 1000

Distance from table surface to spindle nose		 mm 120-920 120-920 120-920 220-1220 220-1220 220-1220
220-1220 220-1220 220-1220 220-1220 220-1220 220-1220 220-1220 220-1220

Distance between two columns		 mm 1900 1900 1900 2400 2400 2400
2800 2800 2800 2800 3600 3600 3600 3600
Worktable
Worktable size mm 1500*2500 1500*3000 1500*4000 1800*3000 1800*4000 1800*5000
2000*3000 2000*4000 2000*5000 2000*6000 2500*3000 2500*4000 2500*5000 2500*6000

Max.load bearing of table		 kg 9000 10000 12000 12000 14000 16000
12000 15000 18000 22000 15000 18000 22000 25000
T T slot size mm 7-22*200 7-22*200 7-22*200 9-22*200 9-22*200 9-22*200
9-22*200 9-22*200 9-22*200 9-22*200 11-28*200 11-28*200 11-28*200 11-28*200
Spindle
Main motor power kw 15/18.5 15/18.5 15/18.5 15/18.5 15/18.5 22/26
15/18.5 15/18.5 22/26 22/26 22/26 22/26 22/26 22/26
Spindle speed rpm 6000 6000 6000 6000 6000 6000
6000 6000 6000 6000 6000 6000 6000 6000
Spindle torque N.m 572 572 572 572 572 560
572 572 560 560 560 560 560 560
Spindle taper
BT50 BT50 BT50 BT50 BT50 BT50
BT50 BT50 BT50 BT50 BT50 BT50 BT50 BT50
Feed
(X/Y/Z) Rapid feed speed m/min 15/15/10 15/15/10 15/15/10 15/15/10 15/15/10 10/15/10
15/15/10 15/15/10 10/15/10 10/15/10 12/15/10 12/15/10 10/15/10 10/15/10
Accuracy
Positioning accuracy mm 0.03 0.03 0.03 0.03 0.03 0.045
0.03 0.03 0.045 0.045 0.03 0.03 0.045 0.045

Re-positioning accuracy		 mm 0.018 0.018 0.018 0.018 0.018 0.02
0.018 0.018 0.02 0.02 0.018 0.018 0.02 0.02
Machine
Machine dimension mm 7900*6000*5000 8800*6000*5000 10800*6000*5000 8800*6200*5500 10800*6200*5500 12800*6200*5500
8800*6600*5500 10800*6600*5500 12800*6600*5500 16000*6600*5500 8800*7400*5700 10800*7400*5700 12800*7400*5700 16000*7400*5700
()Machine weight t 26 28 30 34 37.5 41
35.5 39 43 46.5 41 44.5 48 52


SP1016 SP1020 SP1325 SP1330 SP1525 SP1530 SP1540 SP1820
SP1830 SP1840 SP1850 SP2230 SP2240 SP2250 SP2260 SP2530 SP2540 SP2550 SP2560
Working range
X X aixs travel mm 1650 2050 2600 3100 2600 3100 4100 2050
3200 4200 5200 3200 4200 5200 6200 3200 4200 5200 6200
Y Y aixs travel mm 1100 1100 1400 1400 1650 1650 1650 1850
1850 1850 1850 2250 2250 2250 2250 2900 2900 2900 2900
Z Z aixs travel mm 600 600 800 800 800 800 800 1000
1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000

Distance from table surface to spindle nose		 mm 160-760 160-760 160-960 160-960 160-960 160-960 160-960 260-1260
260-1260 260-1260 260-1260 220-1220 220-1220 220-1220 220-1220 220-1220 220-1220 220-1220 220-1220
Distance between two columns mm 1250 1250 1400 1400 1650 1650 1650 2000
2000 2000 2000 2400 2400 2400 2400 3000 3000 3000 3000
Worktable
Worktable size mm 1600*1000 2000*1000 2500*1300 3000*1300 2500*1500 3000*1500 4000*1500 2000*1800
3000*1800 4000*1800 5000*1800 3000*2000 4000*2000 5000*2000 6000*2000 3000*2500 4000*2500 5000*2500 6000*2500

Max.load bearing of worktable		 kg 3500 4000 6000 7000 6000 7000 8000 10000
12000 14000 16000 12000 15000 18000 20000 15000 18000 22000 25000
T T-slot size mm 7-22*125 7-22*125 7-22*160 7-22*160 9-22*160 9-22*160 9-22*160 11-22*160
11-22*160 11-22*160 11-22*160 11-22*160 11-22*160 11-22*160 11-22*160 11-28*200 11-28*200 11-28*200 11-28*200
Spindle
Main motor power kw 15/18.5 15/18.5 15/18.5 15/18.5 15/18.5 15/18.5 15/18.5 15/18.5
15/18.5 15/18.5 22/26 15/18.5 15/18.5 22/26 22/26 22/26 22/26 22/26 22/26
Spindle speed rpm 8000 8000 6000 6000 6000 6000 6000 6000
6000 6000 6000 6000 6000 6000 6000 6000 6000 6000 6000
Spindle torque N ยท m 143 143 143 143 143 143 143 143
143 143 140 572 572 560 560 560 560 560 560
Spindle taper
BT50 BT50 BT50 BT50 BT50 BT50 BT50 BT50
BT50 BT50 BT50 BT50 BT50 BT50 BT50 BT50 BT50 BT50 BT50
Feed
(X/Y/Z)Rapid feed speed m/min 20/20/12 20/20/12 10/10/10 10/10/10 10/10/10 10/10/10 10/10/10 10/10/10
10/10/10 10/10/10 10/10/10 10/10/10 10/10/10 10/10/10 10/10/10 10/10/10 10/10/10 10/10/10 10/10/10
Accuracy
Positioning accuracy mm 0.03 0.03 0.03 0.03 0.03 0.03 0.03 0.03
0.03 0.03 0.045 0.03 0.03 0.045 0.045 0.03 0.03 0.045 0.045
Re-positioning accuracy mm 0.018 0.018 0.018 0.018 0.018 0.018 0.018 0.018
0.018 0.018 0.02 0.018 0.018 0.02 0.02 0.018 0.018 0.02 0.02
Machine
Machine dimension mm 6000*4000*4100 6800*4000*4100 7800*5500*5000 8800*5500*5000 7900*5800*5100 8800*5800*5000 10800*5800*5000 6800*6000*5500
8800*6000*5500 10800*6000*5500 12800*6000*5500 8800*6400*5500 10800*6400*5500 12800*6400*5500 16000*6400*5500 8800*7200*5700 13700*7200*5700 12800*7200*5700 16000*7200*5700
Machine weight t 18 19 22.5 23 24 26 28 28
32 35.5 39 33.5 37 41 44.5 39 42.5 46 50

Detailed Photos
Gear head type Belt type Direct tye
