| Technical Parameters | | | | | ||||
| Item | | | Standard Value | Maximum Value | ||||
| Processing Capacity | Maximum bar material through-hole diameter | | 25mm | 26mm | ||||
| | Maximum granule diameter (disc type) | | 200mm | 300mm | ||||
| | Maximum processing work piece length | | 150mm | 180mm | ||||
| | Stainless steel single side cutting amount | | 2mm | 2.5mm | ||||
| | Work piece applicable machining accuracy | | ±0.01mm | - | ||||
| | Machined surface smooth finish | | 1.6Ra | - | ||||
| | Tool rest center height | | 40mm | - | ||||
| | Machine tool turning diameter | | 250mm | - | ||||
| | Square knife specifications | | 16mm | - | ||||
| Travel | X axis effective travel (diameter) | | 500mm | - | ||||
| | Z axis effective travel | | 180mm | - | ||||
| Feed | X axis fast moving speed | | 25m/min | 30m/min | ||||
| | Z axis fast moving speed | | 25m/min | 30m/min | ||||
| | X axis servo power | | 1.3KW | - | ||||
| | Z axis servo power | | 1.3KW | - | ||||
| Spindle | Maximum spindle speed | | 3500rpm | 4000rpm | ||||
| | Spindle motor power | | 2.2KW | - | ||||
| | Spindle nose model | | A2-4 | - | ||||
| | Hydraulic chuck available dimensions | | 5 inches | 6 inches | ||||
| Size & Weight | External dimensions | | Estimated 1700*1400*1600mm | - | ||||
| | Overall weight / Net weight | | Estimated 1400KGs | - | ||||
| Machine Tool Specifications and Component Items | | Specifications | Standard Configuration | Optional Configuration | ||||
| Component Specifications | Lead screw | 25mm | Taiwan grinding precision ball screw | - | ||||
| | Guide rail | 25mm | Taiwan H-class linear guide rail | - | ||||
| | Axle bearing | - | Chinese brand fore part 2 rear 2 high speed bearings | | ||||
| | Spindle motor | 2.2KW | Frequency conversion drive type | 3.7KW servo spindle | ||||
| | Feed servo | 1.3KW | Yashu & DMC invent joint developed high speed servo | - | ||||
| | Numerical control system | - | Yashu - KaiTong joint developed system | GSK / Taiwan SYNTEC / Others | ||||
| Machine Tool Specifications | Lathe bed form | 30 degrees | Slanting bed lathe | - | ||||
| | Base form | - | Heavy duty anti deformation patented base | - | ||||
| | Clamping method | - | Hydraulic clamping | - | ||||
| Optional Devices for the Machine | Fly cutter / End face or side face 1 live tooling / End face or side face 2 live tooling / Guide brush support / Vibration plate automatic feeding device / Oil bar feeder / Full automatic feeder | | | | ||||
| * Tips: The above configuration parameters are for reference only and are subject to the listed configurations and physical acceptance based on the price composition. | | | | | ||||
