600*600 2mm Conductive PVC Flooring ESD Tiles Wholesale

US$5.98 1,000 Square Meters (MOQ)

Basic Info.

Model NO.
XYD
Material
PVC
Size
600*600mm
Function
Fireproof, Waterproof, Anti-static
Surface Treatment
UV
Color
White Grey
Metal Type
PVC
Certification
ISO, Floorscore
Usage
Electrical Factory, Computer Room
Advantage
Long Life of Usage
Customized
Non-Customized
Thickness
2mm 2.5mm 3mm
OEM Service
Available
Transport Package
Cartons with Pallets
Specification
600*600*2mm
Trademark
Titan Flor
Origin
China
HS Code
39181090
Production Capacity
100, 000sqm/Year

Product Description

Product introduction The anti-static plastic floor uses the Anti-static network to make it have anti-static function and has good decorative effect. The product is mainly used in electronic computer room, clean room, program-controlled switch room and electronic equipment manufacturing. The production facilities of the microelectronics industry, such as production plants, sterile rooms, central control rooms, etc., require purification and anti-static floor decoration. It is widely used in banking, post and telecommunications, railway, transportation, medicine, microelectronics industry, electronic instrument industry and other fields.
Item
Standards

Conductive floor

Dissipative floor
Thickness EN428 2.0mm 2.5mm 3.0mm
Size EN426 600*600mm/900*900mm 600*600mm/900*900mm
Weight EN430 2.0mm-3.8kg/m2; 2.5mm-4.8kg/m2; 3.0mm-5.8kg/m2

Electric Properties
DIN511953 ASTMF-150 OR NFPA99 2.5*104~106 ohm 106~109 ohm

Decay Time
SJ/T10694-2006(1000V +/- 100V <= 2s) Equal 0.4s Equal 0.4s

Charge Voltage
SJ/T10694-2006( V < 100V) Equal 70 Equal 70

Combustion Properties
SJ/T11236-2001 (<10s) Equal 0.35SFV-0 Equal 0.35S FV-0
Fire Resistance GRADE DIN4102 B1 B1
Wheel Pressure EN425 No Influence No Influence

Amount of anti-wear
SJ/T11236-2001 (<=0.020g/cm2 1000R) Equal 0.014 Equal 0.014

Anti-wear Properties
EN660PT2 ITEN-T<2.0 mm3 ITEN-T<2.0 mm3

Residual Concavity
EN433/DIN51955 0.03mm (2.0mm)
0.035mm (2.5mm)
0.04mm (3.0mm)
0.03mm (2.0mm)
0.035mm (2.5mm)
0.04mm (3.0mm)

Color Fastness
ISO105BO2 At least 6 At least 6

Dimensional Stability
EN434 >=0.10% >=0.10%

Resistance to chemicals
DIN423/DIN51958 Offers excellent resistance ask for special sheet Offers excellent resistance ask for special sheet
Impact sound absorption VLI,ISO104,ISO717 Approx 2dB Approx 2dB

MODEL SELECTION:
FAQ
1.How can we guarantee quality? Each step is strictly controlled by the QC team to make sure all our products turn out
great, we apply 5 years warranty for all our product. 2.Do you offer free samples? Yes, free samples are available. 3.What is your delivery time? Normally in 7 days once getting the deposit for 20ft container. We will update delivery time according to the exact order details. 4.Do you supply installation support? For countries and area we have partners, we can offer installation support. Otherwise, we
support online guidance. 5.What are your payment terms? General term is T/T 30% deposit, balance 70% paid against copy of B/L. We also accept L/C, Trade Assurance, Paypal, Western Union.
