| US$19,999.00-99,999.00 | 1 Set (MOQ) |
| Product Name | Turnkey Project Canned Vegetable Production Line(Processing line) |
| Application | Canned Pepper,Canned Olives,Canned Cucumber,Canned Mushrooms,Canned Bamboo Shoots,Canned Beans,Canned Garlic,Canned Pickles |
| Operation mode | Fully automatic / semi-automatic (customized) |
| Capacity | It can be customized according to the capacity |
| Support bottle type | Glass Bottle,Iron Cans,Plastic Jar |
| Name | Funtion&Specifications |
| 1. Bubble washing machine | Bubble(dry bean 0.5T--1T/H) |
| 2. Sorting size | Size of products |
| 3. Module Conveyor | |
| 4.Module lifting Conveyor for waste material | |
| 5. Lifting conveyor | |
| 6.Conveyor | Used for product conveying |
| 7. Vegetables slicing machine | Peeling of products for |
| 8. Belt Conveyor:select +dicing conveyor | |
| 9. Tank | |
| 10.Liquid filling device | |
| 11. Platform | |
| 12.Gas Exhauste | |
| 13.Press soup filling after | |
| 14.Capping machine | |
| 15.Sterilization machine | |
| 16.Unscrambler table for bottle | |
| Packing Line | |
| 17. filled cans washing and drying machine | Clean the residue on the can |
| 18. Lid loading machine+Capping machine | Seal the jar |
| 19. high pressure sterilization machine | Sterilize cans |
| 20. drying system | |
| 21.case packer | Load the product into cartons |
| 22.palletizer(can and carton) | Stack products together |
| 23. Wet glue labeling machine | Labeling cans |
| 24. date ink-jet printer | Date printing of cans |
| 25. rotated turntable include motor driving conveyor | Used for conveying products |
| 26. manually base box packing paltform | |
| 27. automatic wrapping machine | Wrap the packaged products together |
| | Fruit and vegetable Cleaning Machine 1, raw materials under the action of pressure and force bubbles sink was fully broken up, turn the flow, cleaning, transfer. 2, The device is an efficient cleaning ability, energy-saving, water-saving, avoiding the waste of resources to reduce production costs 3, the device has a relatively wide range of applications, mainly for: Vegetables, fruits, mushrooms, fish and other granular, leafy, root cleaning products, soaking, sterilization and fixing the like. |
| Empty Bottle De-palletizer Empty cans de-palletizer is mainly composed of lifting mechanism, moving mechanism, magnetic suction mechanism, conveyor and electrical controlling system. The working way adopts magnetic suction and moving type. It can match with magnetic lifting conveying system, can transport product in the air and can transport product among different height of floor. | |
| Empty Bottle washing and drying machine Clamping Bottle Washing machine is new type of bottle washing machine,which was developed This machine is a new type of bottle washing machine,which was developed and designed by Shanghai Leadworld Machinery Technology Co., Ltd on based on absorbing European,USA,Germany advanced technology.The machine use high temperature resistant gripper to grip the bottle,and is applicable to wash many different bottle shapes. | |
| Auto Weight and Filling Machine This machine is suitable for glass jar,iron cans,plastic jars,big mouth bottle and so on.Mainly used to Beans,Peach Flap,Peach Strip,Hawthorn,Strawberries,Grapes,Apricots,Lychee,Braise in soy sauce meat.Mutton, pork,chicken,fish and so on,any kinds of solid products canning measuring and filling. | |
| Bottle Selaing Machine The sealing machine is a machine that seals the containers containing products. Automatic vacuum sealing equipment, especially suitable for tin cans, aluminum cans Glass bottle and other bottle types. | |
| Sterilization Machine It is mainly applied to all kinds of cans of drinks, tin cans of drink, canned fruit, canned vegetables and secondary sterilization plastic bottle beverage etc process loading automatically before sterilization,unloading after sterilization,replace the artificial working. | |
| Labeling Machine It Adopts enclosed transmission box,full mechanical transmission, adhesive attached to various round bottle labels,stable and reliable.suitable for round pot labeling. | |
| Palletizer Filled Cans Palletizer is suitable for palletizer and depalletizer of the filled glass bottles,filled tin cans,empty tin cans,it is main composed of conveying system and palletizing system.Working way uses magnetic grabmovement. | |
| Carton Erector The automatic boxopening machine is used to open the carton board, and the bottom of the box is folded according to a certain procedure, then sealed with tape to be delivered to the special equipment of the boxing machine. | |
| Carton Packer Case Packer is to load the products into the box (corrugated box, plastic box and tray) according to a certain arrangement and quantity, and close or seal the opening of the box. | |
| Carton Sealing Machine The sealing machine is mainly applicable to the sealing and packaging of cartons, which can be used together with the assembly line. |
