| US$10,000.00-100,000.00 | 1 set (MOQ) |
| Model | ACE-DNM-2L |
| Output type | 2 lanes |
| Folding speed | 1000 piece/min, depending on the paper quality and napkin size. |
| Raw paper | 13-20g/m2 2-ply, 16-45g/m2 1-ply, wooden pulp paper or nonwoven airlaid. Other sizes please specify. |
| Jumbo roll size | ≤ 660mm x Φ1200mm (Depends on your napkin size, customized) |
| Napkin unfolded size | 330mm x 330mm or Customized. |
| Napkin folded size | 82mm x 165mm One size is fixed. One napkin size is adjustable, by paper roll width. |
| Folding type | Vacuum folding 1/8 1/6 fold. |
| Embossing unit | 1- Steel to paper(wool), Male to female. (Steel to steel is available.) 2- Embossing pattern can be any LOGO, brand name, flowers etc. 3- Embossing pattern can be customized by client or recommended by us 4- Controlled by screws, mechanical pressing type. Cylinder type is optional. |
| Printing unit | 1- Flexo printing type. 2- Printing colors customized up to 8 colors. 3- Printing Logo is changeable. You just need to change the Printing Rubber only. 4- Anilox printing roll. 5- Printing roll is adjustable. 6- Ink printing system to be negotiated. |
| Tension control | Speedless Tension control unit to fit the machine for paper of different quaity and different gsm. With automatic web guiding system. With automatic web tension control system. |
| Calendar unit | Make the napkin softer. |
| Counting | Automatic counting unit |
| Emergent stop | Emergent stop unit to inspect any paper breaks, paper jams. |
| Paper feeding | Synchronizer for feeding paper |
| Power | 7.5Kw for main motor, 11kw for vacuum pump (3-phase AC380V 50Hz or customized) |
| Machine size | 7x2x2m |
| Weight | 4000KG |
| Videos and photos available. | |
