| US$3,000.00-8,000.00 | 1 Piece (MOQ) |
| MODEL SPECIFICATIONS | CA6161 CA6261 CA6161B CA6261B CA6161C CA6261C | |
| Max .Swing over bed | 610mm | |
| Max .Swing over carriage | 370mm | |
| Max .Swing in gap | 830 | |
| Effective gap length | 210 | |
| Max .length of work piece | 750/1000/1500/2000/2200/3000 | |
| Width of bed | 400mm | |
| Section of turning tool | 25×25mm | |
| Spindle | Spindle speed | 10-1400rpm/16-1400rpm(24steps) |
| Hole through spindle | 52mm ,(80mm),[105mm] | |
| Spindle taper | (MT6)(Φ90 1:20)[Φ113:20] | |
| Feed | No. of feed | (64 kinds)(for each) |
| Range of metric threads | (1-192mm) (44 kinds) | |
| Range of inch threads | (1-24tpi) (21kinds) | |
| Range of module threads | 0.25-48 (module 39 kinds) | |
| Range of diametral pitc threads | 1-96DP (37 kinds) | |
| Tailstock | Max. tailstock spindle travel | 150mm |
| Tailstock spindle diameter | 75mm | |
| Taper of tailstock | (MT5) | |
| Main motor | 7.5KW(10HP) | |
| Packing | 750/1000/1500/2000 /2200/3000/4000 | 2440/2650/3150/3650/4030/4800/5680×1140×1750 |
| Weight(kg) | G.W. N.W. | |
| 750mm | 2300 2180 | |
| 1000mm | 2380 2250 | |
| 1500mm | 2577 2437 | |
| 2000mm | 2940 2787 | |
| 2200mm | 3120 2970 | |
| 3000mm | 3600 3450 | |
| 4000mm | 3950 3800 | |
