| Ink type | 2580 solvent based ink |
| Print cartridge type | 45si Print Cartridge optimized for non-porous printing with built-in intelligence |
| Resolution | Up to 600 dpi (recommended 300 x 300 dpi) |
| Nozzle count | 300 |
| Print swath | 12.7 mm (0.5 in) |
| Throw distance | Up to 5 mm |
| Firing voltage | 8.7 V |
| Fire pulse width | 1.8 microseconds |
| Pulse warming | Off |
| Average drop volume | B3F58A: 36 pl |
| B3F58B: 38 pl | |
| Average delivered ink | B3F58A: 35 ml (vertical) and 25 ml (horizontal) |
| B3F58B: 34 ml (vertical) and 31 ml (horizontal) | |
| Number of electrical interconnect pads | 52 + 4 (printhead + Smart card) |
| Operating conditions | 15 to 35° C / 59 to 95° F, 35 to 80% RH |
