* Suitable platform weighing,bed weighing,etc.
| Maximum capacity(Emax) | 1.0t |
| Accuracy class | C3 |
| Approvals | OIML R60 C3 |
| Maximum number of load cell intervals(nLC) | 3000 |
| Ratio of minimum LC verification interval Y=Emax/Vmin | 10000 |
| Combined error | ±0.020%FS |
| Creep | ±0.016%FS/30min |
| Temperature effect on sensitivity | ±0.011%FS/10ºC |
| Temperature effect on zero | ±0.015%FS/10ºC |
| Output sensitivity(=FS) | 3±0.003 mV/V 2.0±0.002 mV/V |
| Input resistance | 350±3.5 Ω |
| Onput resistance | 350±3.5 Ω |
| Insulation resistance | ≥5000MΩ(50VDC) |
| Zero balance | ±1.0%FS |
| Compensated temperature | -10ºC~+40ºC |
| Operating temperature | -35ºC~+70ºC |
| Excitation,recommended voltage | 5V~12V(DC) |
| Excitation maximum | 18V(DC) |
| Safe overload | 150%FS |
| Ultimate overload | 300%FS |
| Recommended torque on fixation | M12: 100N.m; M18: 200N.m; M24: 700N.m |
| Ingress protection(according to EN 60529) | IP67 |
| ATEX classification(optional) | operating temperature: -20ºC~+40ºC |
| II1G Ex ia II1C T4 | II1D Ex iaD20 T73ºC | II3G Ex nL II C T4 |
| "S1" output sensitivity is 2.0±0.002MV/V |
