Basic Info.
Main Application
Water, Diesel Fuel, Fuel Oil
Application
Industrial Production
Measuring Principle
Electrical Principles
Measurement Object
Closed Pipeline
Connection
Flange Clamp Thread
Transport Package
Carton or Wooden Case
Production Capacity
5000 Unit/Units Per Month
Packaging & Delivery
Package Size
15.00cm * 20.00cm * 20.00cm
Package Gross Weight
3.000kg
Product Description
Specification
| Product Parameters |
| Precision | DN4-DN10: ±1.0%R ; DN15-DN100: ±1%R ; DN125-DN200: ±1.0%R |
| Ratio of Measuring Range | 1:10 |
| Instrument Material | Sensor:PE ; Impeller: PE ; Guide: PE ; Bearing: ceramic (special
material can be customized) |
| Conditions of use | Environment temperature: -30ºC-50ºC |
| Medium temperature: -30ºC-50ºC |
| Pressure Level | Threaded connections:1.0MPa |
| Flange connections :0.1MPa |
| |
| Power Suppiy | 3.6V lithium battery (can be used continuonsly for 2 years) /12-24VDC |
| Power Consumption | ≤1W |
| Signal Output | Pulse / 4-20mA / RS485(Modbus-RTU) |
| Signal Interface | Internal thread M20*1.5(NPT1/2, etc needs to be customized) |
| Protection Level | IP65 (IP68 can be customized) |
| Explosion-proof Level | ExdllCT6 Gb |
| Display | LCD instantaneous flow , accumulative flow unit( m³/h;L/min;L/h;Kg/h;Kg/min
;GPM) settable |
Anhui Jujie Automation Technology Co., Ltd. is a research and development, production, sales in one of the automation
instrument high-tech enterprises.Company have experienced team of professional sales engineers and high-quality products
to ensure better process control solutions for clients! Our main products include: turbine flow meter, electromagnetic flow meter,
vortex flow meter, compression vortex flow meter, ultrasonic flow meter, digital pressure gauge, pressure transmitter, liquid
level gauge,data recorder and other products
>>
