| General | |
| Model | OCBP-020 |
| Interface | USB/USB+Bluetooth/USB+LAN |
| Printer Head life | 50KM |
| Power adaptor | Input:AC 100-240V, 50~60Hz ; Output:DC 24V/1.5A |
| Sensors | Dual-media sensors: transmissive and reflective |
| Printer driver | Windows, MAC OS , Support IOS / Android |
| Font and barcode rotation | 0°,90°,180°,270° |
| Printer command | TSPL command (CPCL/ESC/POS command-optional) |
| Printing capability | |
| Printing method | Direct line thermal |
| Resoluiton | 203 DPI |
| Print speed | 120mm/s |
| Print width | 20-76mm |
| Available Max Paper Width | 80mm |
| Barcode and character | |
| Barcode | 1D barcode: UPC-A / UPC-E / JAN13 (EAN13) / JAN8 (EAN8) / CODE39 / ITF / CODABAR / CODE93 / CODE128 2D barcode: QR Code, PDF417 |
| Media | |
| Media type | continuous paper, label paper, folded paper, tag paper |
| Media width | Max 80mm |
| Media thickness | 0.06-0.30 mm |
| Media core diameter | 25.4mm |
| Paper roll diameter | 100mm (MAX) |
| Physical | |
| Physical dimension | 200*160*139.5mm |
| Weight | Net:1.02kg , Gross1.40kg |
| Package box | 235*220*170mm |
| 8 in one carton | 490*460*360mm/12kg |
| Accessories | USB cable,User Manual,Power adaptor |
| Environment | |
| Working temperature& humidity | 5 to 40 degrees centigrade, 25%~85% No condensation |
| Storage temperature& humidity | -40 to 60 degrees centigrade , 10%~90% No condensation |
