Product Description
Product Description
Product Description11mm 250m Fiberglass cable pusher electric conduit snake push pull frp duct rodderGreat Rigidity Fiberglass Push Pull, FRP duct rod, Cable duct rodder is selected as a special tool for pulling electric cables and optical fiber cables in telecom, power industries, buildings and many other fields. The rod is made of fiberglass and high strength resin at high temperature, it is coated by high density polyethylene engineering plastic as its protected layer, which makes the duct rodder cover sliding on surface, durable, corrosion resistant and has good insulation performance, these make it safe for using in cable occupied duct. Along with pull head and handcart, it features easy to move and operate. The fiberglass duct rodder will be equipped with different size of reels in accordance with the length of the rod, there are wheels on the reel to make it convenient for moving, it is an ideal tool for laying cables.SpecificationRod diameter:φ4mm φ6mm φ7mm φ8mm φ9mm φ10mm φ11mm φ12mm φ13mm φ15mmRod Length:50-500mMaterial:Fiber glass rid inner: Extruded by fiber glass and high strength resin at high temperatureFiber glass rod outer:High Density polyethylene coatingMetal Frame:Steel with high-temperature sprayed plastic or hot dip galvanizedFiber glass content:75-80%Density:> 1.9gr/cm3Working environment:-40 to +80Min Bending Radius:298mmMinimum Pulling strength：4000N +/-5%Color:Red, Yellow, Green, Blue, Black, White, and so on , we accept customized Fiberglass Fish Tape Cable Rods Cable Laying Tools 11*300m Duct Rodder partsMeter marks: There are meter marks on the rod for the user easily read it. The marks is waterproof, ultraviolet and it can bestill clear even after using long time.Its outer protected layer is made of high density ABS resin,which has good anti-UVcapability, the advantage of smooth, wear-resistant and long service life.Rod grapple: The duct rodder is also equipped with the rod grapple on the steel frame. Rod grapple set on the end of the rod is commonly used to pass through the conduit when the conduit is plugged by sand, soil or other things.Rod guide: Rod guide of the duct rodder is used to push and draw back the fiberglass rod. The fiberglass rod can easily pass through the rod guide avoiding unnecessary fraction and wear. At the same time, we can also produce the rod guide with double pulley to satisfy your diversified demands.How to choose the size?ApplicationSuitable diameterNotesWire/Network cable5-8mmUsed for building pipes, wall perforated traction wires and network cableslamp-post8mmTraction wireCable Cable Length ≤ 200m 10-12mmWhen connecting, the tractor head of the duct rodder the fiber-optic cable link with a rope and iron wire. On the other side,pull back while turning the pay-off car to wrap the duct rodder back on the frame until it passes through the pipe.Cable Length ≥200m 14mm100-200m pipe length Seven-hole/five-hole quintux pipe 11-12mm100-200m pipe length 110 wave pipe 12mm100-150 pipe length ≥100 pipe 13mm About 180m ≥100 Communication pipe14mmAbout 200m ≥200 Power Piping 16mm When pulling a power cable, you must use a duct rodder to pass through the pipe, then pull a tension rope or steel wire rope first,and use the steel wire rope to pull the cableProducts ShowFiberglass Fish Tape Cable Rods Cable Laying Tools 11*300m Duct Rodder picture details High-quality plastic steel wireFRP lead is imported alkali-free fiber, full of elasticity, anti-aging, durableThickened steel pipe,Thickened steel pipe, thickened reinforced steel pipe, not easy to rust, export quality, long-term useWear-resistant wheelRubber wear-resistant wheels, easy to implement, durable and wear-resistant, long service lifeProduction processFiberglass Fish Tape Cable Rods Cable Laying Tools 11*300m Duct Rodder process ApplicationFiberglass Fish Tape Cable Rods Cable Laying Tools 11*300m Duct Rodder Appliation Packing&ShippingThe inner packing: Plastic woven strip wind around the cable duct rodder frameThe outer packing: Put into a cartonIf the quntity of the cable duct rodder is LCL,we will use the wodden palletOur CertificationsFAQQ: Are you trading company or manufacturer ?A: We are factory.Q: How long is your delivery time?A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.Q: Do you provide samples ? is it free or extra ?A: Yes, we could offer the sample for free charge but do not pay the cost of freight.Q: What is your terms of payment ?A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.If you have another question, pls feel free to contact us as below:
>>
