Hydraulic Toilet Paper Plastic Packaging Bags Press Cutting Machine (HG-B60T)

US$19,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
HG-B60T
Automation
Automatic
Suitable for
Plastic, Rubber
Product Name
Plastic Packaging Cutting Machine
The Warranty
1years
Feeding Side
1 or 2
Cylinders
Two
Columns
Four
Cutting Area
810*1400mm
Cutting Force
60tons
Control
by Computer Control, PLC Control
Automatic Grade
Manual to Automatic
Suitable for Material
Sponge,Foam,Plastic,Leather,EVA/EPE/PS/PVC/PE etc.
Transport Package
Plastic Film or Packed in Wooden Cases
Specification
CE
Trademark
honggang
Origin
Guangdong Foshan
HS Code
847780000
Production Capacity
3000sets/Years

Product Description

Hydraulic Toilet Paper Plastic Packaging Bags Press Cutting Machine (HG-B60T)
The cutting machine used for die cutting disposable blister or foam packing,EPE foam packaging,automatic/plane interiors etc.large materials sheet 1.Features and Advantages1.controlled by PLC(programmable logic controller),with touching screen,to set and micro-adjust working pressure,cutting depth,feeding speed easier,faster and more precise.
2.double automatic working tables,increases ther output twice or triple.
3.auto-balance structure of double-cylinder,four-column and self-balance connecting rod,makes sure equal pressure any working area.
4.powered by hydraulic system,slow down when the cutting die touches material,to confirm the precision between upper and bottom for thick materials.
5.central automatic lubrication system,increases machine durability,prolong the working time. 2.Product Specification
Model Cutting Force Dimension/(mm) Cutting Area Moter Stroke Net Weight
HG-B60T 60 Tons 3000*2300*1570 810*1400mm 5.5kw 50-240mm 4500kg
HG-B80T 80 Tons 3000*2300*1570 810*1400mm 7.5kw 50-240mm 5000kg
HG-B100T 100 Tons 3000*2300*1570 810*1400mm 7.5kw 50-240mm 5500kg
HG-B120T 120 Tons 3000*2300*1570 810*1400mm 11kw 50-240mm 6300kg
HG-B150T 150 Tons 3000*2300*1570 810*1400mm 11kw 50-240mm 7000kg
Remark:Cutting force can be from 50 tons to 300tons;cutting area can be (610/710/810/910mm)×(1400/1600/1800mm),etc
3. The Cutting Machine Working Show 4. Application Materials:The Cutting Machine is widely used in industrial leather,plastic,rubber,sponge,foam,EVA,PVC,cardboard,paper products,fabric,home textiles,packaging materials,non woven,carpet,car cushion,felt,synthetic materials,and other non-metallic materials in various industries;Extremely suitable for cutting multiple layers of material at one time,etc.
5. FQA: 1)What's warranty of machine?
12 months Warranty Life-long maintenance service for machine
2)What's your after-sales service?
Engineer available to serve machines over seas;
Email and calling service in working hour; 24 hours door to door in domestic.

3)Can we test the our material by your machine free?
Yes, please contact us to send your matrial.

4)How to confirm how much ton pressure is fine?
Always 1m knife line need about 5 ton pressure.
please send your drawing or product photo, we can help you confirm.

5)Can you make dies & PP boards?
Yes, just send your drawing or material.
PP board will come with machine to you.

6)Are you a factory or trading company?
We are a factory and manufacturer

Don't know how many ton you need?
Please contact us!

If you are not sure if your material can be cut by this cutting machine,we want to know the product information:
Material:
Max. material width:
Max. material thickness:
Max.cutting length:
