Ski Bike Motorcycle Motocross Helmet Fast Injection Moulding Machine with Fast Clamping Unit

US$38,800.00
1 Piece
US$33,800.00
2 Pieces
US$28,800.00
3+ Pieces

Basic Info.

Model NO.
ST-480A
Type
Injection Blow Molding
Structure
Horizontal
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008
Product Name
Injection Molding Machine
Function
Plastic Parts Production
Motor
Servo Energy Saving
Machinery Size
12.38m*2.8m*3.5m
Advantage
Energy Saving
Application
Plastic Products
Model No.
St-480A
Machine Color
Blue+White
Certificate
CE
Transport Package
Woollen Case
Specification
12.38m*2.8m*3.5m
Trademark
SINOTECH
Origin
Made in China
HS Code
8462299000
Production Capacity
50-600PCS/Hr

Product Description

ski bike motorcycle motocross helmet fast injection moulding machine with fast clamping unit
Product Description
SINO-TECH ST-480A injection molding machine is designed for plastic dustbin, chairs, car bump pallet etc. It is with demoulding linkage which shorten the plastic parts cycle time. ST-480A with high speed, stable performance and it is energy-saving. Our customers can get higher production with same labor and cost.
Main Features1. 30% higher energy saving than using traditional variable pump.
2. Stable and smooth movement supported by AC servo motor.
3.Effective reduction of energy consumption due to reduced oil.and cooling water attained by hydraulic system.
4. High performance European B&R control system.
We are professional plastic injection molding machine manufacturer for all kinds of plastic products, Clamping force from 70 to 1600Ton, injection weight from 50 to 10000g. Also we have CE and ISO certification.
Product Parameters
Item 1000JSell
Screw diameter mm 100 110 125
Theoretical shot volume cm³ 3848 4657 6013
Shot weight (PS) g 3646 4191 5412
Length/Diameter ratio L/D 22.3 20.0 17.7
Injection pressure(high pressure and low speed) MPa 215 178 138
Injection pressure(low pressure and high speed MPa 156 129 100
Injection rate(high pressure and low speed) cm³/sec 671 812 1048
Injection rate(low pressure and high speed) cm³/sec 925 1119 1445
Plasticizing capacity (PS) g/s 93 118 154
Injection stroke mm 490
Screw speed rpm 115
Injection unit force Ton 20.0
Carriage stroke mm 920
Clamping force Ton 1000
Opening force Ton 106.1
Opening force Ton 34.7
Max. daylight mm 2400
Clamping stroke mm 1200-1800
Distance btwn. Tie bars mm 1210*1060
Min mould dimension mm 840*740
Mould thickness range mm 600-1200
Ejector force Ton 21.5
Ejector stroke mm 300
No. of ejector pins unit 21
Dry Cycle(Euromap 6) S 5.7
Major motor kW 105.2
System pressure MPa 17.5 22.1
No. of heater zones unit 5+1
Heater input power kW 56
Ultimate capacity kw 162.2
Current A 197.2
Net weight Ton 45.5
Oil filling capacity L 1800

Detailed Photos

Application

Company Profile

FAQ
1. who are we?We are based in Jiangsu, China, start from 2011,sell to North America(30.00%),South America(20.00%),Western Europe(16.00%),Oceania(10.00%),Mid East(10.00%),Eastern Europe(5.00%),Southeast Asia(5.00%),Africa(4.00%). There are total about 5-10 people in our office.2. how can we guarantee quality?Always a pre-production sample before mass production;Always final Inspection before shipment;3.what can you buy from us?Extrusion Blow Molding Machine,Pet Blow Molding Machine,IBC Cage Production Line,Plastic Extrusion Line,Waste Plastic Recycling And Pelletizing Line4. why should you buy from us not from other suppliers?Our company have the strict system from the material purchase,machine part processing and inspect. We have the detailed Assemble prcess according to the machine Assemble structure. We test not one time before the machine delivery to the customer factory.5. what services can we provide?Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery;Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
