Peanuts Chocolate Bar/Small Capacity /SGS Chocolate Snack Compound Candy Bar /Cramel Bar / Energy Bar / Big Capacity Candy Machine

Product Description

Name: Compound Cooling Roller .


Product Description: It is compose of two part of cooling roller , and the width is design according to the product size and output capacity. Installed on stainless steel platform. It can press the material which from the Kitchen area , and the loading machine will transfer peanuts to the nuts feeder which connected with this roller.
Name : Vacuum Mixer Cooker
Function : cooking the syrup which transfer from the melting tank, and vacuum mix the finished cooker material , mix with nuts finally. Steam pressure: .0.8Ma material: 304 stainless steel Electricity:28kw ,2400x2600x3500mm Capacity: 150kg/batch /20Minutes Controll panel: Maual or Automatic (Can be custmomized) Enrobing Machine With Cooling Tunnel : Application :
This enrobing line is to coat chocolate on various food ,such as biscuit ,wafers, egg rolls,cake pie and snacks etc. Cooling tunnel is available. There are following special devices for optional also: 1.Automatic feeder: Simplify the feeding of biscuits or wafers etc to the enrobing wire mesh.
2.Granular sprinkler: Sprinking peanut granulars or sesame on the surface of coating products.
3.Carving : Carve beautiful pattern on the surface of enrobing products.

Item /Model	400	600	900	1000	1200
Wire mesh and belt width(mm)	400	600	900	1000	1200
Wire mesh and belt speed(m/min)	2.5-4	2.5-4	2.5-4	2.5-4	2.5-4
Refrigeration unit (set)	2(set)3HP	3(set)3HP	3(set)5HP	3(set)5HP	4 (set)5HP
Cooling Tunnel length (m)	10	13.5	15.5	17.5	20
Cooling Tunnel Temperature(ºC)	2-10	2-10	2-10	2-10	2-10
Total power(kw)	16	16.5	22.87	25	28.5
Weight(kg)	1800	2300	3200	3500	4050
Dimensions	1200x700x1500	15500x950x1800	17500x1200x1800	19500x1200x1800	22000x1450x1800

Name:Strip Cutter:
Product Description:
Power:3.7kw
Strip cutting machine with motor direct connect to prevent knife slipping, we coat knife with Teflon, knife cooling by fan.
Motor:Redsun
Electric parts:Schneider Name :Vertical Cutter
Product Description: Servo motor with touch panel, knife with Teflon, push bar is driven by servo motor can set bar length and cut in continuous way.
Electricity:3.95 kw
Touch Screen: DELTA
Servo motor: DELTA
Electric parts:Schneider
Products produce :
Packing &Shipping

1.Plsatic Film with Woodern Box Covered
2.Reinforce with metal wire and wood board in container
3.Delivery time: 90 working days or depend on Custom
Factory&Exhibition

Factory Patent
FAQ
1.What is your company advantage ?
We have own factory ,designed and manufacture by ourself. Near the Qingdao port, it is very convinent for exporting . Cheap than European machine, short delivery time than Germany machine.
2.What is the payment terms?
T/T or L/C , 30% advance deposit ,70% before loading .
3.Where is the factroy location?
Dongying City ,Shandong Province, China, North of the China. 4.Could you please send me your best price?
Before quoting, please kindly consult us and provide a.The type of confectionery you will produce.
b.The size of your product, your expected capacity for the line or machine

---
