CE Split Core Current Transformer 150A/5A ID 24mm Low Voltage CT

Product Details

Product Description

Product Description
Xh-Sct-T24
Specifications Of SCT-T24 Split Core Current Transformer
Maximum continuous primary current 5A to 300Aac
Output: 5A
Accuracy: ± 1% from 5% to 120% of rated current
Insulation Voltage: 600VAC
Maximum Primary Voltage: 3kV(Insulated Conductor)
Phase angle: Less than 2 degrees at 50% of rated current
Frequency Range: 50 Hz to 400 Hz
Operating Temperature: -15C to 60C.
CE recognized, and RoHS compliant
Output and leads can be customized

Model	Input(A)	Output(A)	Overload current(A)	Accuracy(5%-120%)F(I)%	Accuracy(5%-120%)δ(I)°
XH-SCT-T24B-100A/5A	100	5	160	≤1.5%	≤1.5°
XH-SCT-T24B-150A/5A	150	5	240	≤1%	≤1°
XH-SCT-T24B-200A/5A	200	5	320	≤1%	≤0.5°
XH-SCT-T24B-250A/5A	250	5	420	≤1%	≤0.5°
XH-SCT-T24B-300A/5A	300	5	420	≤1%	≤0.5°

Drawing Size Of SCT-T24 Split Core Current Transformer
