BestScope BS-2036DT Infinity Plan 3W LED Rechargeable Biological Trinocular Microscope

Product Description

Introduction
BS-2036 series microscopes are middle level microscopes which are specially designed for college education, medical and laboratory study. They adopt high quality optical system, beautiful structure and ergonomic design. With an innovative optical and structure design idea, excellent optical performance and easy to operate system, these biological microscopes make your works enjoyable.
Feature 1. Excellent optical system Excellent optical system, outstanding image quality with high resolution and definition. 2.Ergonomic design Comfortable operating with ergonomic design. Back handle and observing hole convenient for carry and operation.
3. Unique aspheric illumination system
Unique aspheric illumination system, provide bright and comfortable lighting. 4. Color for optional White color is standard, blue color is optional for lively environment and happy mood. 5. Viewing head Brand new and humanized butterfly binocular head-tubes can be 360° rotated to raise observing height 44mm than normal tubes to be more convenient for users with different height.
6. Power supply
Built-in LED illumination system which can be powered with power bank, laptop and vehicle power supply ensures being used anywhere and any condition
7. Various accessories for upgrading
Wire winding device convenient for carry and storage (optional).
Phase contrast unit, independent phase contrast unit (optional, apply to infinite optical system).
Simple polarizing unit with polarizer and analyzer (optional).
Dry / Oil Dark Field Condenser (optional).
Application
BS-2036 series microscopes are ideal instrument in biological, histological, pathological, bacteriology, immunizations and pharmacy field and can be widely used in medical and sanitary establishments, laboratories, institutes, academic laboratories, colleges and universities.
Specification

Item	Specification	BS-2036AT	BS-2036BT	BS-2036CT	BS-2036DT
Optical System	Finite Optical System	*	*
	Infinite Optical System			*	*
Viewing Head	Inclined 30° binocular tube, 360° rotatable, interpupillary distance: 48-75mm	○	○	○	○
	Inclined 30° trinocular tube, 360° rotatable, interpupillary distance: 48-75mm, splitting ratio: eyepiece: trinocular=20:80	*	*	*	*
Eyepiece	Wide field eyepiece WF10X/18mm	*
	High eyepoint wide field eyepiece WF10X/20mm		*	*	*
	WF16X/13mm	○	○	○	○
	Reticule eyepiece WF10X/18mm (0.1mm)	○
	Reticule eyepiece WF10X/20mm (0.1mm)		○	○	○
Achromatic Objective	4X, 10X, 40X(S), 100X/NA 1.25 (Oil) (S)	*
	20X, 60X (S)	○
Plan Achromatic Objective	4X, 10X, 40X/NA 0.65 (S), 100X/NA 1.25 (Oil) (S)		*
	20X, 60X (S)		○
Infinite Achromatic Objective	E-Plan 4X, 10X, 40X (S), 100X (Oil) (S)			*
	Plan 4X, 10X, 40X (S), 100X (Oil) (S)				*
	Plan 20X, 60X (S), 100X (Water) (S)			○	○
Infinity Plan Semi-Apochromatic Fluorescent Objectives	4X/NA=0.16, WD=17.15mm			○	○
	10X/NA=0.30, WD=7.68mm			○	○
	20X/NA=0.50, WD=1.96mm			○	○
	40X/NA=0.75, WD=0.78mm			○	○
	40X/NA=0.75, WD=0.78mm (for TB, no correction of slide cover)			○	○
	(Oil) 100X/NA=1.3, WD=0.15mm			○	○
Nosepiece	Backward Quadruple Nosepiece	*	*	*	*
	Backward Quintuple Nosepiece	○	○	○	○
Focusing	Coaxial coarse & fine focusing knobs, travel range: 26mm, Scale:2um	*	*	*	*
Stage	Double layers mechanical stage, size: 145mm*140mm, cross travel 76mm*52mm, scale 0.1mm, two slide holders	*	*	*	*
	Rackless double layers mechanical stage, size: 140mm*135mm, cross travel 75mm*35mm, scale 0.1mm, two slide holders	○	○	○	○
Condenser	Abbe condenser NA1.25 with iris diaphragm	*	*	*	*
Illumination	3W LED lamp, brightness adjustable	*	*	*	*
	6V/20W Halogen lamp, brightness adjustable	○	○	○	○
	6V/30W Halogen lamp, brightness adjustable	○	○	○	○
Field Diaphragm	Field diaphragm	○	○	○	○
Dark Field Condenser	N.A.0.9 (Dry) Dark field condenser (for 10X-40X objectives)	○	○	○	○
	N.A.1.3 (Oil) Dark field condenser (for 100X objective)	○	○	○	○
Polarizing Set	Analyzer and Polarizer	○	○	○	○
Independent Phase Contrast Unit	Infinite Plan Phase Contrast 10X			○	○
	Infinite Plan Phase Contrast 20X			○	○
	Infinite Plan Phase Contrast 40X			○	○
	Infinite Plan Phase Contrast 100X			○	○
	Phase contrast slide			○	○
	Condenser			○	○
	Telescope			○	○
	Green filter			○	○
Fluorescence Attachment	B/G Epi fluorescence unit (six-hole disc media which can be fixed with UV/V/B/G and another filters), 100W mercury lamp.			○	○
	UV/V/B/G Epi fluorescence unit (six-hole disc media which can be fixed with UV/V/B/G and another filters), 100W mercury lamp.			○	○
	B/G Epi fluorescence unit (six-hole disc media which can be fixed with UV/V/B/G), 5W-LED fluorescence lamp.			○	○
	UV/V/B/G Epi fluorescence unit ( six-hole disc media which can be fixed with UV/V/B/G), 5W-LED fluorescence lamp.			○	○
	B or G fluorescence unit, 5W-LED fluorescence lamp.			○	○
	Auramine long pass fluorescence unit, with 5W LED fluorescence lamp			○	○
	B/G fluorescence unit, 5W-LED fluorescence lamp.			○	○
Filter	Blue filter (Φ45)	○	○	○	○
	Green filter (Φ45)	○	○	○	○
	Yellow filter (Φ45)	○	○	○	○
Photo Adapter	Used to Connect Nikon/Canon/Sony/Olympus DSLR camera to the microscope	○	○	○	○
Video Adapter	0.5X C-mount adapter, adjustable focus	○	○	○	○
	0.75X C-mount adapter, adjustable focus	○	○	○	○
	1X C-mount adapter, adjustable focus	○	○	○	○
	Trinocular digital eyepiece interface	○	○	○	○
Mirror	Reflect Mirror	○	○	○	○
Cable Winding Device	Used to wind cable on back of the microscope	○	○	○	○
Rechargeable Battery	3pcs AA rechargeable Nickel-metal hydride battery	○	○	○	○
Package	1pc/carton, 42cm*28cm*45cm, Gross Weight 8kg, Net Weight 6.5kg	○	○	○	○

Note: *Standard Outfit, ○OptionalSample Images

---
