Mechanical Seal Spare Parts Copper Carbon Brush Carbon Graphite Seal Ring

Product Description

Mechanical Seal Spare Parts Copper Carbon Brush Carbon Graphite Seal Ring
Description:
Carbon graphite seal rings or faces are typically molded to a rough shape before being impregnated with resin or metal binder Carbon fill with metal/antimony carbon seal faces or rings are especially subject to corrosion but a suitable resin filled carbon seal faces or rings can usually be found for most services. Carbon graphite seal faces or rings are not recommended for aqua regia, oleum or perchloric acid. Resin-impregnated carbon seal rings or faces in common use are attacked by lithium hydroxide, potassium hydroxide, sodium metophosphate, anhydrous ammonia, sodium diphosphate and sodium cyanide. A metal filled carbon graphite seal face or ring is generally better in strength, hardness and modulus of elasticity than resin filled carbon graphite seal faces or rings.
Operating Range:
1)The graphite seal rings are available and tailor-made as customers' request.
2)The graphite seal rings with wear resistance,resistance to high temperature,pressure resistance,corrosion resistance,creep resistance,self-lubricating without oil,little expansion coefficient,and excellent sealing.

Grade	Density	Compressive strength	Flexural sttrength	Hardness	Open Porosity	Use Temperature	C.E.O
M120	1.60g/cm³	81Mpa	25 Mpa	60	18%	350ºC	4
M154	1.50g/cm³	45Mpa	20 Mpa	40	28%	350ºC	4
M106H	1.65g/cm³	180-190 Mpa	51-60 Mpa	65-90	1.0%	200ºC	4.8
M120H	1.72g/cm³	176-182 Mpa	49-55 Mpa	65-90	1.0%	200ºC	4.8
M254H	1.82g/cm³	74-100 Mpa	35-45 Mpa	42-55	1.0%	200ºC	4.5
M106K	1.70g/cm³	182-200 Mpa	55-65 Mpa	75-95	2.0%	200ºC
M120K	1.75g/cm³	179-185 Mpa	50-60 Mpa	70-95	2.0%	200ºC
M158K	1.70g/cm³	179-181 Mpa	54-60 Mpa	75-85	1.2%	200ºC
M106D	2.2-2.5g/cm³	170-190 Mpa	55-65 Mpa	75-80	3.0%	500ºC	4.5
M120D	2.2-2.5g/cm³	140-160 Mpa	50-60 Mpa	70-80	3.0%	500ºC	5.0
M254D	2.2-2.5g/cm³	60 Mpa	35 Mpa	35	3.0%	500ºC	4.5

resin carbon seal ring: resin carbon seal face
antimony carbon seal ring: antimony carbon seal face
carbon sea faces: carbon seal ring
antimony carbon seal faces: anttimony carbon seal rings
antimony carbon seal face: antimony carbon seal ring
Product Categories
We are one of the largest Chinese professional designer and manufacturer various styles of mechanical seal.Graphite Gaskets Ring Seal Gasket ,of graphite carbon products.many products like carbon brush for power tools, generator,starters,Auto, carbon blade, graphite plate, carbon vanes for vacuum pumps, carbon bearing,carbon seal, carbon sheet, carbon rod, graphite raw material, graphite crucible, graphite bearing and so on
We have first-class technology, professional engineer, advanced production equipment and inspection. Our main products include: O-ring mechanical seals, PTFE wedge mechanical seals, elastomer bellow shaft seals, metal bellow mechanical seals, cartridge seals and O.E.M seals, which are interchangeable to equivalent Bgm, JohnCrane, Aesseal,Vulcan, Roten. Besides that, we also manufacture and stock many thousands of specific pump seals:A.B.S,Alfa Ebara,EMU,Flygt,Fristam,Grundf, Hidrostal,Inoxpa,Lowara,Waukesha,Wilo. We also can supply seal materials include Ceramic, carbon, silicon carbides, Ssic, tungsten carbides and various of stainless steel parts. Our products sell all over the world and get good feedback from our customers, please action now, we will supply competitive price, great after-sales service and quick response.
As Follows Our Warehouse
We are always committed to the imported mechanical seals localization and have accumulated a wealth of experience .
Our product range includes Component Seals, Metal Bellow Seals, Cartridge Seals, Agitator seals, Dry Gas Seals and Split Seals.
To great our service, we present the products and solutions while using the very good top quality at the reasonable cost for Metal Bellow Mechanical Seals. To ensure you get what exactly you need, our professional team will help you work through all the details straight to your target. With our powerful team support, you would not have to worry about anything. Our company establishes the management system in strict accordance with the requirements of international standards and makes detailed after-sales service commitment.
FAQ 1. who are we? Are you trading company or manufacturer ?
We are manufacturer.We are based in Hangzhou, China, start from 2010,sell to Domestic Market(33.00%),North America(15.00%),South America(10.00%),Western Europe(8.00%),Eastern Europe(6.00%),Souther Europe(6.00%),Southeast Asia(5.00%),Mid East(5.00%),Northern Europe(5.00%),Oceania(2.00%),South Asia(2.00%),Africa(00.00%),Eastern Asia(00.00%),Central America(00.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production; Always final Inspection before shipment;
3.what can you buy from us?
PTFE Seals/Oil Seals/O Rings/Rubber Seals/Plastic Seals/Mechanical Seal/O-RING/ RING Seals.
4. why should you buy from us not from other suppliers? Beseals is a professional manufacturer of seals .Our company specializes in the production of PU, PTFE, rubber and metal sealing components
5. How long is your delivery time? Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
6.Do you provide samples ? is it free or extra ? Yes, we could offer the sample for free charge but you need to pay the cost of freight. 7. what services can we provide? Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,Express Delivery; Accepted Payment Currency:USD,EUR,JPY,CAD,HKD,CNY; Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,PayPal,Western Union,Escrow; Language
Spoken:English,Chinese,Japanese
For more information, please contact us. We look forward to your arrival

---
