C6280c Large Diameter Multi Function Lathe Machine with Bar Feeder From China

Product Description

C6280C Large Diameter Multi Function Lathe Machine With Bar Feeder From China
Product Application CF SERIES LARGE SPINDLE HOLE PRECISION LATHE: * The surtace of the bedways is supersonic frequency.
* The spindle bore size is 105mm. The spindle system is high in rigitidy and accuracy.
* There is no need for change gears. The machine can turn about 89 kinds of metric, Inch, Module and D.P. threads.
* An automatic stopping device is used to realize automatic stop for the machining of a workpiece of a certain length.

Product main technical parameters:

TEMS	C6250C	C6266C	C6280C
	1000/1500/2000/3000/4000mm
Max. swing over bed	500mm	660mm	800mm
Max. swing over carriage	300mm	420mm	560mm
Max. swing over gap	710mm	870mm	1010mm
Max. turned diameter	500mm	660mm	800mm
Maximum length of work piece	1000mm/1500mm/2000mm/3000mm/4000mm
Effective length in gap	230mm
Spindle nose	D8
Spindle nose	105mm
Spindle taper of bore	113mm 1: 20
Number of speeds	12 steps
Spindle speed scope	36-1600 rpm/13-1400rpm
Thread Metric pitches	1~14mm/22
Thread imperial pitches	28~2 TPI/26
Thread diametral pitches	56~4 D. P/24
Thread Module pitches	0.5~7mm/18
Range of feeds for longitudinal	0.063-2.52mm (0.023" ~0.937" )
Range of feeds for cross	0.027-1.07mm (0.010" ~0.404" )
Rapid traverse for longitudinal	4.5m/min
Rapid traverse for cross	1.9m/min
Max. travel of top slide	145mm(5-3/4" )
Max. travel of cross slide	360mm(14-3/16" )
Max. size of tool(WxH)	25× 25mm(1" × 1" )
Tailstock sleeve dia.	75mm(2-61/64" )
Tailstock taper of bore	M. T. No. 5
Tailstock sleeve travel	150mm(5-29/32" )
Power of main motor	7.5kw
Overall dimensions(L× W× H) (mm)	2500/3200/3700/4200/4700/5700x1150x1800mm

Product Details
Packing shipping
For machine: usually by sea;
For documents: by international express, eg. DHL,TNT or EMS.
For packing :Free fumigation plywood packaging steel base
our service
1. Technical support online service provided.
2. Technical files service provided.
3. Machine operation video provided
4. On-site training service provided.
5.Spare parts replacement and repair service provided.
6 All of the questions will be replied within 8 hours
7. If you need to develop products with your own specification, we can help you to work it out.
8. Always be honest, never lie to customer, and never declare anything we don't have
Company Information
Since 1996,20 years' history for machine tool manufacturing
10 years' history for export
Total 2 manufacturing bases in china
Sino-germany technology cooperation
Production of 8 categories, more than 130 kinds of products
Set up design&research center at TAIWAN
Exported to total 48 countries in the world covered most areas
One-stop shopping for nearly all other types' machine tools
1:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
3: Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277500 China. You are warmly welcomed to visit us.
4. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
5: What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
6: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
We want to know:
1.What's your Industrial Voltage?
2.We strongly suggest you to tell us size, material of your workpiece for our evaluation, if possible, better to send us workpiece drawing, so that we can recommend you most suitable model!
3.If need CIF Price, please kindly tell us the port of destination.

---
