High Speed Automatic Paper Bag Printing Machine

Product Description

Feature:
1) The main motor adopts imported inverter to govern a stepples speed adjustment.
2) Feeding and rewinding are controlled through magnetic particle brake and clutch.
3) Un winder system is controlled by edge guide sensor.
4) Adopt ceramic anliox roller which offers durability, wear resistance and corrosion resistance, also is more efficient on production by reducing the times of changing rollers.
5) The printing units are all equipped with a group of infrared dryers respectively .
6) Each IR dryer device of printing unit is interchangeable to UV dryer.
7) Un winder and re winder adopt air core holder.
8) The printing unit can register in 360 degrees. Each printing unit can be independently geared and loosen to have rest of units continue to printing.
9) The roll feeding, printing, UV vanish, auto infrared drying, laminating and rewinding can be processed in one pass. It has characterized by wide application, fast printing speed and high economic efficiency Ink will not contaminate environment.
So it is an idea printing machine for the business form, Tag and high end pressure sensitive label.
Product Made from Machine:
Teachnical Specifications:

Max. Web Width	320mm
Max. Printing Width	310mm
Printing Repeat	180mm-380mm/min
Color	2~6
Thickness of Substrate	0.1~0.3mm
Machine Speed	10m-80m/min
Max. Unwind Diameter	600mm
Max. Rewind Diameter	550mm
Main Motor Capacity	2.2kw
Main Power	380V/AC 3 phase 50HZ
Overall Dimension(LxWxH)	3000x1500x3000mm
Machine Weight	2000kg

*lts overall dimension and manufacturing Process are subject to change without further notice.
Detail Configuration:

Name	Model	Quantity	Unit
Turn bar	320	1	set
IR Dryer	320	6	set
Tension control system Unwinder		1	set
Web-guiding		1	set
Lamination device		1	set
Waste rewinding device		1	set
Rotary Die-cutting station		1	set
Rewinding tension control		1	set
Air shaft	3 inch	2	Piece
Adjusting handle for left/right		1	set
Plate roller	320	18	set
Ceramic	320	6	Piece
Motor	wangnan	1	set
invert	Teco	1	Piece
Magnetic power	50N	1	pcs
Magnetic clutch	50N	1	pcs
Low press apparatus		1	Set

Machine Detailed Pic for Reference:
