Basic Info.
Usage
Mining Excavator, GM Excavator
Transmission
Hydraulic Transmission
Drive Type
Internal Combustion Drive
Certification
CE, ISO9001: 2000
Rated Power
22.2kw/2200rpm
Transport Package
Container
Specification
4730*1700*2470 mm
Production Capacity
500/Year
Product Description
Product Description
RELIABILITY
engine, strong performance, high reliability, low noise design
Electrically controlled power control, more power, stronger, more fuel consumption
Customized main control spool, more precise micro-control
Slope turning is effortless with the leading rotary and travel motors
Product Parameters
| Operating weight | 3800 kg |
| Bucket capacity | 0.12 m3 |
| Bucket digging force(standard) | 30 kN |
| Arm Digging Force | 19 kN |
| Max traction | 35.1 kN |
| Max. Walking Speed | 4.2 km/h |
| Min. Walking Speed | 2.7 km/h |
| Swing speed | 8.4 r/min |
| Gradeability | 30° |
| Ground pressure | 34.7 kPa |
| Model | YANMAR 3TNV88F |
| Rated Power | 22.2kW/2200rpm |
| Cylinder | 3 |
| Displacement | 1.642 L |
| Max. Torque/Speed | 103/1800N·m/rpm |
| Max. Main Pump Flow | 108 L/min |
| Main Safety Valve Pressure | 24.2 MPa |
| Max digging height | 4251 mm |
| Max Dumping height | 3410 mm |
| Max. Digging Depth | 2915 mm |
| Max vertical digging depth | 2625 mm |
| Max. Digging Radius | 5225 mm |
| Max. Ground Digging Radius | 5015 mm |
| Min. Turning Radius | / mm |
| Dozer Blade Height | 348 mm |
| Transportation Dimensions(L*W*H) | 4730*1700*2470 mm |
| Tail swing radius | 850 mm |
| Track length | 2094 mm |
| Ground clerance | 300 mm |
| Counterweight clerance | 537 mm |
| Fuel tank capacity | 40 L |
| Hydraulic oil tank | 20 L |
| Engine oil | 6.7 L |
Detailed Photos
