US$0.53-0.98
|
500 Pieces
(MOQ)
|
Basic Info.
Classification
Male Connector
Connector Type
Qma Connector
Plating
Tri-Alloy and Gold
Specification
Inner Conductor
Origin
Zhenjiang City, Jiangsu Province, China
Production Capacity
500000pieces/Year
Packaging & Delivery
Package Size
19.00cm * 9.00cm * 6.00cm
Package Gross Weight
0.500kg
Product Description
RF coaxial QMA Male plug Crimp Connector For LMR240 Cable B
| Model No. | QMA-C-J240B |
| Interface | IEC 60169 |
| Electrical | |
| Characteristic Impedance | 50ohm |
| Frequency Range | DC-6GHz |
| VSWR | ≤1.25@DC-3GHz; ≤1.35@DC-6GHz |
| Working Vlotage | ≤480V |
| Dielectric Withstanding Voltage | ≥1000V RMS,50Hz,at sea level |
| Dielectric Resistance | ≥5000MΩ |
| Contact Resistance | Center Contact ≤3mΩ | Outer Contact ≤2.5 mΩ |
| Mating | - |
| Mechanical | |
| Durability | Mating cycles ≥500 |
| Interface retention force | ≥60N |
| Material and Plating | | |
| Parts Name | Material | Plating |
| Body | Brass | Tri-alloy |
| Insulator | PTFE | - |
| Inner Conductor | Phosphor Bronze | Au |
| Outer Conductor | Phosphor Bronze | Tri-alloy |
| Ferrule | Annealed Copper | Ni |
| Operating Temperature | -40 ºC-85 ºC |
| RoHs Compliant | Yes |
Pictures Show:
Family products:
Company Information:
Founded in 1994, Four Star Communication Parts Co.,Ltd is located in No.88 S338 Road Zhenjiang City, Jiangsu Province China (230Km away from Shanghai).
Four Star Communication is one of the excellent manufacturer dedicating to design and make RF coaxial connectors, RF cable assembly, Microwave components.
Our products range:
RF coaxial connectors Series : SMA ,SMB,SMC, BNC,TNC, N,7/16 DIN , 1.0/2.3,1.6/5.6 ,SMZ (BT43) ,QMA ,FME,F,UHF,MCX,MMCX,EIA Flange, 4.3/10 etc.
RF coaxial Cable assembly(Jumper Cable)
Micro-wave Components : Dummy Load(Terminator), Attenuator, Surge Arrestor(Surge Protector), Power Splitter (Divider), Directional Coupler.
>>
