Polished 99.95% Pure Tungsten and Tungsten Alloy Sheet

Product Description

Polished tungsten plate tungsten sheet and W1 tungsten sheet
Size: Thickness 0.05-50.0mm Width 20-800mm Length 100-3000mm or as your need
Tungsten sheet/plate/foil/strip
Specification:
1) Tungsten Sheet/Plate Purity: 99.95%
2) Density: >19.1g/cm3
3) Size: according to the needs of users: T(0.03-40)*W(20-600)*L L<2000mm
4) Surface: Black,Alkali Wash and Polished
5) Condition: hot roll, cold roll.
6) Products Application: Tungsten is suitable for light, electric vacuum device, electric semiconductor device, glass fiber kiln heating element, heat shield, boat and finished products etc.
Tungsten Alloy plate/sheet/rod Content: Material: WCu (W50 W55 W60 W65 W70Cu, W75Cu, W80Cu, W85Cu, W90Cu, etc) Product standard: GB8320-87
Density:11.85-16.75g/cm3
Size:As your need Plate: (0.04-50)* W X L rod-Dia.1.5 - 200 X 300mm Long
WCu alloy foil size: Thickness(0.08-0.7mm)*Width<120mm*Length<300mm
Tungsten High Heavy Alloy Tungsten copper alloy Specification:
Material:
WNiCu (W90Ni6Cu4, W92, W95, W97.5, W90Ni7Cu3, etc)
WNiFe (W90Ni7Fe3, W92, W95, W97.5, W90NiFe, etc) Density: 16.8g/cm3-18.85g/cm3
W heavy alloy foil size: Thickness(0.1-100mm)*Width<120mm*Length<300mm
W heavy alloyRods Size: dia(1.5 -200) x Length<500mm 99.95% W Tungsten plate tungsten sheet tungsten foil Thin tungsten sheet size and tolerance as follows:

Thickness mm	Tolerance of thickness		Width	Tolerance of Width	Length	Tolerance of Length
	First Glass	Two glass
0.10~0.15	±0.01	±0.02	50~200	±2	100~1200	±5
>0.15~0.30	±0.02	±0.03	50~200	±2	100~1200	±5
>0.30~0.50	±0.03	±0.04	50~200	±2	100~1200	±5
>0.50~0.70	±0.04	±0.05	50~200	±3	100~1200	±5
>0.70~1.0	±0.05	±0.08	50~200	±3	100~1200	±5
>1.0~2.0	±0.06	±0.10	50~200	±5	100~1200	±5
>2.0~3.0	±0.08	±0.15	50~200	±5	100~1200	±5
>3.0~4.0	±0.10	±0.20	50~200	±5	100~1200	±5
>4.0~5.0	±0.12	±0.30	50~200	±5	100~1200	±5

Pure tungsten bar sheet Specification: Surface:Black and polished Purity:≥99.95% Density:≥19.2g/cm3, Surface roughness:<1.6 Dia:2.5-120mm
Property specification 1) high melting point, high strength, 2) smooth and clean surface, 3) good conductions, small linear expansion coefficient and good heat-resistance
Tungsten copper alloy rod and sheet/plate Specification: Material: W50-90 Cu10-50 WCu (W70Cu30, W75Cu, W80Cu, W85Cu, W90Cu, etc) Density: 11.85g/cm3-16.75g/cm3 Product standard: GB8320-87 WCu alloy foil size: Thickness(0.08-0.7mm)*Width<120mm*Length<300mm WCu alloy sheet size: diameter(3-100mm)*L<500mm
Flatness tolerance:<4um
Roughness:Ra1.6-Ra0.8
Surface: polished, ground.
Molybdenum sheet/plate/foil/strip-Mo1/MoLa/TZM
99.95% Molybdenum Sheet, Molybdenum Strip 0.3mm 0.5mm Thickness
1. Purity: Mo>= 99.95%
2. Standard: GB/T 4182 or ASTM
3. Property specification
1) high melting point, high strength,
2) smooth and clean surface,
3) good conductions, small linear expansion coefficient and good heat-resistance.
Thinner Molybdenum Sheet Molybdenum Foil Mocu Sheet Tzm Molybdenum Sheet
1. Purity: Mo>= 99.95%
2. Standard: GB/T 4182 or ASTM
3. Property specification
1) high melting point, high strength,
2) smooth and clean surface,
3) good conductions, small linear expansion coefficient and good heat-resistance

	Thickness (mm)	Width(mm)	Length(mm)	Surface	Rolled condition
Molybdenum Plate	8.0-16.0	10-1000	10-1000	Alkali washed	Hot rolled
	3.0-8.0	10-1000	10-1000		Hot rolled
Molybdenum sheet	1.5-3.0	10-1000	10-2500	Acid cleaning	Coled rolled
	0.5-1.5	10-1000	10-2500		Cold rolled
	0.2-0.5	10-1000	10-2500		Cold rolled

Our main products:
Molybdenum Products
Molybdenum rods/ Molybdenum plate /Molybdenum sheet
Molybdenum wire/ alloy Molybdenum wire/ Moly wire for EDM
Molybdenum electrode/molybdenum disk/Molybdenum boat/ Molybdenum Crucible/Molybdenum tube
Tungsten Products
Tungsten rods/ Tungsten plate/ Tungsten sheet
Tungsten wire/ Tungsten electrode
Tungsten crucible /Tungsten boat/ Tungsten tube
Other specail shape/part
Alloy Products
TZM Products/MoLa products, WC, Ti, Ta, Ni, etc.
WNiFe / WniCu Product/ Alloy ball/WC-Co
Tungsten fishing products
Tungsten bead, tungsten alloy shot for hunting, tungsten metal material
More information about us:
We promise you -- The advantage of us: 1) products quality, with many years of producing experience 2) low price in the market, and factory direct sales. 3) the whole production line from powder to finished products, top and steady quality assured
4) good packing for safe exprot delivery, and fast manufacturing time 5) fast delivery and best after-sale service.

---
