Xt-X-8A Operating Microscope Is Mainly Used in Otorhinolaryngology, Neurosurgery, Urology and Microsurgery and Animal Experiments

US$2,200.00-100,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
XT-X-8A
Material
Steel and Aluminum
Feature
Reusable
Group
Adult
Product Features
1.Large Field of View Binocular Microscope, Wide D
Transport Package
Wooden Box
Trademark
xin cheng
Origin
Zhejiang, Jiangsu, China

Product Description

Purpose
XT-X-8A operating microscope is mainly used in otorhinolaryngology, neurosurgery, urology and microsurgery and animal experiments.
Product Features
1.Large field of view binocular microscope, wide diameter optical fiber, three-dimensional sense of strong, high resolution, clear image.
2.The primary mirror has six degrees of freedom of movement, and manual adjustment is easy and flexible.
3.The binocular lens barrel was observed at a variable angle of 0°-90°.
4.Beautiful appearance, electric foot control fine-tuning focus, the operation is more reliable and convenient.
Technical parameters 1.microscope section
Eyepiece 0-90 variable angle observation binocular lens barrel, 10X Alf type wide-angle eyepiece
Visual adjustment ± 6D (binocular)
front and rear adjustment range -45-45
left and right adjustment range -30-30
interpupillary distance 55mm-75mm
magnification 4X-20X ,manual infinity continuous magnification
field diameter 12.5mm-60mm
working distance ≥ 200mm (standard) (optional for 250, 300 and 400)
1:8 large variable ratio 2. lighting system
Form wide-diameter light guide fiber, cold light source coaxial lighting
light source double lamp 15V/150W, German OSRAM halogen lamp
light source double lamp 15V/150W, German OSRAM halogen lamp
control mode four-level dimming
illuminance ≥ 50000LX
power supply voltage and frequency 220V ± 10% 50Hz

3. base part
Cross arm extension length 1050mm
up and down adjustment range ≥ 230mm
foot control electric fine adjustment focus 40mm 10%

Optional Accessories
1. Splitter
2. CCD system
3. Camera system
