Xt-X-8A Operating Microscope Is Mainly Used in Otorhinolaryngology, Neurosurgery, Urology and Microsurgery and Animal Experiments

Product Description

Purpose
XT-X-8A operating microscope is mainly used in otorhinolaryngology, neurosurgery, urology and microsurgery and animal experiments.
Product Features
1.Large field of view binocular microscope, wide diameter optical fiber, three-dimensional sense of strong, high resolution, clear image.
2.The primary mirror has six degrees of freedom of movement, and manual adjustment is easy and flexible.
3.The binocular lens barrel was observed at a variable angle of 0°-90°.
4.Beautiful appearance, electric foot control fine-tuning focus, the operation is more reliable and convenient.
Technical parameters 1.microscope section

Eyepiece	0-90 variable angle observation binocular lens barrel, 10X Alf type wide-angle eyepiece
Visual adjustment	± 6D (binocular)
front and rear adjustment range	-45-45
left and right adjustment range	-30-30
interpupillary distance	55mm-75mm
magnification	4X-20X ,manual infinity continuous magnification
field diameter	12.5mm-60mm
working distance	≥ 200mm (standard) (optional for 250, 300 and 400)

1:8 large variable ratio 2. lighting system

Form	wide-diameter light guide fiber, cold light source coaxial lighting
light source	double lamp 15V/150W, German OSRAM halogen lamp
light source	double lamp 15V/150W, German OSRAM halogen lamp
control mode	four-level dimming
illuminance	≥ 50000LX
power supply voltage and frequency	220V ± 10% 50Hz

3. base part

Cross arm extension length	1050mm
up and down adjustment range	≥ 230mm
foot control electric fine adjustment focus	40mm 10%

Optional Accessories
1. Splitter
2. CCD system
3. Camera system

---
