| US$500.00 | 1 Piece (MOQ) |
| Type | Model | Parameters | |
| Separate type | THJ-F2-20 | Capacity(L/H) | 2,000-20,000 |
| Max pressure(Bar) | 3 x 10 | ||
| Impeller dia(mm) | 170 | ||
| Inlet(mm) | 80 | ||
| Liquid inlet(mm) | 8 x 1.5 | ||
| Outlet(mm) | 8 x 1.5 | ||
| Motor(kw) | 4, 5.5, 7.5 | ||
| R.E.V(rpm) | 2000-2900 | ||
| Type | Model | Parameters | |
| Vertical Integrative Type | THJ-L2-10 | Capacity(L/H) | 2,000-10,000 |
| Max pressure(Bar) | 3 x 10 | ||
| Impeller dia(mm) | 170 | ||
| Inlet(mm) | 80 | ||
| Liquid inlet(mm) | 8 x 1.5 | ||
| Outlet(mm) | 8 x 1.5 | ||
| Motor(kw) | 4 | ||
| R.E.V(rpm) | 2900 | ||
