Hello, we are a professional AR & VR equipment manufacturer. We can provide AR VR equipment of various specifications to meet the needs of various entertainment and business scenes. Please feel free to contact me for further information.
| OPTICAL |
| Model Type | Birdbath |
| Diopter | The diopter can be adjusted to 0 ~ -500 degrees |
| Ppupillary distance is optional |
| According to 63.5/58.5/67 |
| DISPLAY |
| Device Type | Si-OLED * 2 |
| Contrast | 100000:1 |
| Brightness | 2000nits |
| Resolution | 1920x1080xRGB @0.49 inch |
| Refresh rate | 75 hz |
| FOV | 41 ° |
| Virtual Screen | 63-320 inches (2m~10m) |
| Color | 24 |
| AUDIO |
| Speaker | Stereo speakers * 2 |
| INTERFACE |
| USB Type-C | Wired |
| Video I/F | DisplayPort Alternate Mode (DP Alt Mode) |
| DisplayPort | Version 1.4 |
| Audio codec | LPCM (32kHz to 192kHz) |
| EDID | Supported |
| Power | 5.0 V 0.5 A |
| USB protocol | USB2.0 |
| Data Type | Sensor data, firmware update |
| SENSOR |
| A compass | Yes |
| Gyroscope | Yes |
| Accelerator | Yes |
| KEYS |
| Short press width Key (+ / -) |
| 2D/3D Switch to Long Press Brightness Key (-) |
| Short press Volume Key (+ / -) |
| GENERAL |
| Operating temperature and Humidity 5°C~35°C, 20% to 80% Humidity |
| Store temperature and Humidity -10°C~60°C, 10% to 90% Humidity |
| W177 mm x D159mm x H48 mm x T12 mm (top) |
| Weight: about 68g (not including light shield, cable) |
| Accessories: nose rest (optional), sunglasses piece, adjusting screwdriver, erasing cloth |
