| Overall parameter |
| Overall dimension | 9400x2500x3850mm |
| Kerb weight | 14500kg |
| Mixing Drum parameter |
| Mixing drum material | High quality wear-resistance steel |
| Model:Q355 |
| Drum body thickness: 5mm, End cover thickness:6mm |
| Agitating capacity | 10M3 |
| Charging rate | ≥3 m3/min |
| Top feed hopper dimension | ≥650 mm |
| Discharging rate | ≥2 m3/min |
| Residual rate | ≤0.5% |
| Water supply | Baric water supply system |
| Water tank capacity | 450L |
| Radiator | 18L |
| Reduction gear | TOP P68 Reducer, Italy technology |
| Hydraulic pump | ARK PV089 Pump,Italy technology |
| Hydraulic motor | ARK MF089 Pump,Italy technology |
| Accessory | Tool box |
| Chassis parameter |
| Chassis Brand | SINO Truck |
| Chassis model | ZZ1257N3841W |
| Axle base | 3825+1350 |
| Driving type | Left hand drive(LHD) |
| Engine model | WD615.69 |
| Rated power (HP) | 336HP |
| Emission standard | Euro II |
| Fuel type | Diesel |
| Transmission(Gear box) | HW13710 |
| Front axle | Drum type |
| Rear axle | HC16 Driving axle |
| Tyre | 12.00R20(10+1) |
| Cab type | HOWO 76 (with air-conditioner) |
