| MODEL | MD1022 |
| Working table | Table Size (L× W) | mm | 540×250 |
| Max movement of working table(L× W) | mm | 560×260 |
| T -Slot (number×width) | mm | 1×14 |
| | Max distance from spindle center to table surface | mm | 420 |
| Grinding head | Wheel Size(Outer diameter×width×Inner diameter) | mm | φ200×20×Φ31.75 |
| Wheel speed | 50HZ | r/min | 2850 |
| 60HZ | | 3360 |
| Feed amount | Longitudinal speed of working table | m/min | 3-20 |
| Cross feed of working table | Continuously(Variable Transmission) | mm/min | 150 |
| Intermittently(Variable Transmission) | mm/times | 0-5 |
| Per revolution on handwheel | mm | 4.0 |
| Per graduation on handwheel | mm | 0.02 |
| Vertical feed on handwheel | Per revolution | mm | 1.25 |
| Per graduation | mm | 0.01 |
| Commutation feeder | Total input power | w | 150 |
| X- feeder output speed | R/min | 0-225 |
| X- feeder size | mm | 280×130×120 |
| Y- feeder output speed | R/min | 0-120 |
| Y- feeder size | mm | 280×130×120 |
| Motor power | Spindle motor | kw | 1.5 |
| Coolant pump motor | w | 40 |
| Working precision | The parallelism of working surface to base level | mm | 300:0.005 |
| Surface roughness | μm | Ra0.32 |
| Weight | Net | kg | 880 |
| Gross | kg | 980 |
| Overall dimension(L×W×H) | mm | 1680x1140x1760 |
| Package dimension(L×W×H) | mm | 1200x1400x1940 |
