High-Quality Multistage Vertical Turbine Water Pump

Product Description

Product Description
Introduction of Vertical Turbine PumpVertical single stage or multistage pump with mixed or axial flow impeller design, broad hydraulic coverage provides best selection to meet specific operating conditions. Fabricated or cast iron, surface or underground discharge head, shaft and bearing combinations promote long life with options of open or enclose line shaft construction. It can be driven by VHS NEMA Standard motor, VSS motor or diesel engine through right angle gear box.StructureApplication of Vertical Turbine Pump

Municipal	Waster Plants	Commercial/Industrial
Golf Courses/Turf Irrigation	Agricultural Irrigation	Dewatering
Mining	Cooling Tower	Water Parks
Snowing	Flood Control	River/Sea Water Circulation
Fire-Fighting	etc

Material of Vertical Turbine PumpBowl: Cast iron, Stainless steelShaft: Stainless steelImpeller: Cast iron, Bronze or Stainless steelDischarge head: Cast iron or carbon steel
Basic Parameters

Type	Capacity	Head			Stage	String Quantity	Rotating Speed	Motor Power	Effi	Dia
	m³/h	m			i	mm	r/min	kw	%	mm
100RJC10-4	6.5 10 12	44	40	32	10	8	2940	5.5	62	92
		52.5	44	35	11			5.5
		53	48	38	12			5.5
		58	52	41.5	13			5.5
		61.5	56	44.5	14			5.5
		66	60	48	15			5.5
		70	64	51	16			5.5
		74.5	68	54	17			5.5
		79	72	57.5	18			5.5
		83.5	76	60.5	19			5.5
		88	80	64	20			5.5
		92	84	67	21			5.5
		96.5	88	70	22			5.5
		102	92	73.5	23			5.5
		105.5	96	76.5	24			5.5
		110	100	80	25			5.5
		115	104	83	26			5.5
150RJC10-9	8 10 16	56	54	40	6	12	2940	5.5	62	138
		65	63	47	7			5.5
		74.5	72	54	8			5.5
		84	80	61	9			5.5
		93	89	67.5	10			5.5
		102.5	98	61.5	11			7.5
		112	108	81	12			7.5
		121	117	87.5	13			7.5
		130	126	94.5	14			7.5
		139.5	135	101	15			11
		149	144	108	16			11
150RJC20-11	15 20 24	48	44	39.4	4	12	2940	5.5	67	150
		60	55	49.3	5			5.5
		72	66	59	6			7.5
		84	77	69	7			7.5
		96	88	78.7	8			11
		108	99	88.6	9			11
		120	110	98.4	10			11
		132	121	108.2	11			15
		144	132	118	12			15
		156	143	128	13			15
		168	154	134	14			15
		180	165	147.5	15			18.5
		192	176	157.5	16			18.5
		204	187	167	17			18.5
150RJC30-12.5	21 30 36	55	50	41	4	8	2940	7.5	70	150
		69	62.5	51	5			11
		82.5	75	61	6			11
		96.2	87.5	71.8	7			15
		110.4	100	82	8			15
		124	112.5	92.2	9			15
		138	125	102.5	10			18.5
		151.6	137.5	112.8	11			22
		165	150	123	12			22
150RJC40-13.5	30 40 46	62	54	50	4	8	2940	11	72	150
		77.5	67.5	62.5	5			15
		93	81	75	6			15
		108.5	94.5	87.5	7			18.5
		124	108	100	8			22
		139	121.5	112.5	9			22
		155	135	125	10			30
		170.5	148.5	137.5	11			30
		186	162	150	12			30
150RJC50-13	30 50 55	66	52	46	4	8	2940	11	74	150
		82.5	65	57.5	5			15
		99	78	69	6			18.5
		115.5	91	80.5	7			22
		132	104	92	8			22
		148.5	117	103.5	9			30
200RJC60-20	40 60 76	44	40	30	2	9	2940	11	75	181
		66	60	45	3			18.5
		88	80	60	4			22
		110	100	75	5			30
		132	120	90	6			37
		154	140	105	7			37
200RJC80-22.5	60 80 100	49	45	38	2	9	2940	15	75	181
		73.5	67.5	57	3			22
		98	90	76	4			30
		122.5	112.5	95	5			37
200RJC90-20	67 90 119	45	40	28	2	10	2940	15	75	190
		68	60	43	3			22
		91	80	57	4			37
		114	100	72	5			45
200RJC125-18	89 125 142	21.5	18	15	1	10	2940	11	76	190
		43	36	30	2			18.5
		64.5	54	45	3			30
		86	72	60	4			37
250RJC130-8.5	89 130 150	39	34	28	4	10	1460	18.5	78	242
		49	42.5	35	5			22
		59	51	42	6			30
		69	59.5	49	7			37
		79	68	56	8			37
		89	76.5	63	9			45
		99	85	70	10			45
		109	93.5	77	11			55
		119	102	84	12			55
300RJC160-11.5	125 160 200	39	34.5	28.5	3	14	1460	22	80	295
		52	46	38	4			30
		65	57.5	47.5	5			37
		78	69	57	6			45
		91	80.5	66.5	7			55
		104	92	76	8			75
		117	103.5	85.5	9			75
		130	115	95	10			75
		143	126.5	104.5	11			90
		156	138	114	12			90
300RJC185-12	130 185 235	27	24	18.9	2	14	1460	18.5	80	295
		40	36	28.4	3			30
		54	48	37.8	4			37
		67	60	47.2	5			45
		81	72	56.7	6			55
		94	84	66	7			75
		108	96	75.6	8			75
		121	108	85	9			90
		135	120	94.5	10			90
300RJC220-13.5	154 220 264	29	27	22	2	12	1460	22	80	295
		44	40.5	34	3			37
		59	54	45	4			45
		74	67.5	57	5			55
		89	81	68	6			75
		104	94.5	79	7			90
		119	108	91	8			90
350RJC300-15	230 300 370	35	30	23	2	12	1460	37	80	346
		52.5	45	34.5	3			55
		70	60	46	4			75
		87.5	75	57.5	5			90
		105	90	69	6			110
		122.5	105	80.5	7			132
350RJC370-16	270 370 460	19	16	11.5	1	12	1460	30	80	346
		38	32	23	2			55
		57	48	34.5	3			75
		76	64	46	4			90
		95	80	57.5	5			110
		114	96	69	6			132
350RJC400-18	280 400 480	20.8	18	14	1	12	1460	37	80	346
		41	36	29	2			55
		62	54	43	3			90
		83	72	58	4			110
		104	90	73	5			132
400RJC450-30	290 450 540	35	30	25	1	22	1475	55	80	430
		70	60	50	2			110
		105	90	75	3			150
		140	120	100	4			200
		175	150	125	5			250
400RJC550-27	400 550 850	29	27	17.5	1	20	1475	55	81	430
		58	54	35	2			110
		87	81	52.5	3			180
		116	108	70	4			225
		145	135	87.5	5			280
450RJC650-32	520 650 850	35	32	22	1	20	1475	90	80	520
		70	64	44	2			180
		105	96	66	3			250
		140	128	88	4			350
		175	160	110	5			400
450RJC900-30	600 900 1100	34	30	24	1	20	1475	110	82	520
		68	60	48	2			225
		102	90	72	3			315
		136	120	96	4			400
		170	150	120	5			560
500RJC1000-29	790 1000 1300	33	29	21	1	20	1475	110	83	600
		66	58	42	2			225
		99	87	63	3			350
		132	116	84	4			450
500RJC1250-30	800 1250 1750	36	30	18.5	1	17	1475	150	84	600
		72	60	37	2			280
		108	90	55.5	3			400
		144	120	74	4			560
500RJC2000-31	1500 2000 2400	36	31	25	1	22	1475	250	80	670
		72	62	50	2			500
