| Model | WH-24-12 | WH-24-24 | |
| Output | DC output voltage | 12V | 24V |
| Output voltage tolerance | 1% | 1% | |
| Rated output current | 2A | 1A | |
| Output current range | 0~ 2A | 0~ 1A | |
| output power | 24W | 24W | |
| Ripple and noise | 50mVp-p | 50mVp-p | |
| DC voltage adjustable range | 10% | 10% | |
| Start, rise,hold time | 200ms,50ms,20ms/230VAC | ||
| Input | Input voltage range | 170~264VAC 47~63Hz,235~373VDC | |
| AC input current | 0.35A/230VAC | ||
| efficiency | 78% | 78% | |
| Impulse current | Cold start current 30A / 230VAC | ||
| Leakage current | <0.5mA/240VAC | ||
| Protection | overload protection | 110% - 135% of rated output power start overload protection | |
| Protection mode: fold type current limit, automatic recovery after removal of abnormal load conditions | |||
| Environmental Science | Working temperature and humidity | -10 ºC ~ + 60 ºC; 20% ~ 90% RH (please refer to load derate curve) | |
| Storage temperature and humidity | -20 ºC ~ + 85 ºC; 10% ~ 95% RH non condensing | ||
| Seismic resistance | 10~ 500Hz, 2G 10min. / 1 cycle, duration 60min, each axis | ||
| Security | Pressure resistance | Input output room: 1.5kVac input and ground: 1.5kVac output and ground: 0.5kvac | |
| insulation resistance | Input output room: input and ground, output and ground: 100M ohms / 500VDC | ||
| Other | weight | 0.120kg 83*43*31(L*W*H) | |
| Packing | 100pcs | ||
